- Page 1 User Manual MC61-BYOD Multiformat Presentation Switcher All Rights Reserved Version: MC61-BYOD...
- Page 2 Multiformat Presentation Switcher Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.
- Page 3 Multiformat Presentation Switcher SAFETY PRECAUTIONS To ensure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for ⚫...
-
Page 4: Table Of Contents
Multiformat Presentation Switcher Table of Content 1. Product Introduction ....................1 1.1. Features ....................... 1 1.2. Package List ......................1 2. Specification ......................2 3. Panel Description ..................... 3 3.1. Front Panel ......................3 3.2. Rear Panel ......................4 4. System Connection ....................5 4.1. -
Page 5: Product Introduction
Multiformat Presentation Switcher 1. Product Introduction The MC61 BYOD is a Multiformat Presentation Switcher converting AV signal from Lightning, USB-C, MINI DP, DP, HDMI type-A and HDMI type-D to HDMI. The BYOD is a green low energy consumption product which has a various application in different places, such as classroom, small meeting room, lecture hall, and etc. -
Page 6: Specification
Multiformat Presentation Switcher 2. Specification Input (1) Lighting, (1) Type-C USB, (1) Mini DP, (1) DP, Connector Type (1) Type-A HDMI, (1) Type-D HDMI Lighting Video Resolution Up to 1080P@60Hz USB-C Video Resolution Up to 4Kx2K@30Hz DP Video Resolution Up to 4Kx2K@30Hz HDMI Video Resolution Up to 4Kx2K@30Hz HDMI Version... -
Page 7: Panel Description
Multiformat Presentation Switcher 3. Panel Description 3.1. Front Panel USB - C DP full sized HDMI A HDMI type-D ① Lightning port to connect iOS device, such as iPhone or iPad with charging capability. ② USB-C port to connect MacBook, Chromebook or other devices with SlimPort output. -
Page 8: Rear Panel
Multiformat Presentation Switcher 3.2. Rear Panel 1080P SERVICE RES. DC 24V ① Security lock slot for Kensington lock installing. ② Micro-USB port for firmware upgrade. ③ DIP switch for setting the HDMI output resolution as 4K or 1080P base on the EDID of connected display and source. -
Page 9: System Connection
Multiformat Presentation Switcher 4. System Connection 4.1. Usage Precaution Make sure all components and accessories included before installation. ⚫ System should be installed in a clean environment with proper temperature and ⚫ humidity. All of the power switches, plugs, sockets, and power cords should be insulated and ⚫... - Page 10 Multiformat Presentation Switcher ③ According the below installing direction arrow to insert the BYOD to bracket. Rear Panel Front Panel...
-
Page 11: System Diagram
Multiformat Presentation Switcher 4.3. System Diagram 1080P SERVICE RES. DC 24V 1080P SERVICE RES. DC 24V USB - C DP full sized HDMI A HDMI type-D Preview USB-C PC Graphics card Laptop Cellphone/PAD iPad MacBook Mac Mini... -
Page 12: System Operation
Multiformat Presentation Switcher 4.4. System Operation ① Connect TV to the HDMI output on the rear panel. ② Power on TV and the switcher, and then the TV will show “Please connect your device”. If the switcher doesn’t detect any source within 10 minutes, it will automatically turn off TMDS. -
Page 13: Firmware Upgrade
Multiformat Presentation Switcher 5. Firmware Upgrade Notes: Firmware should be in USB storage Home Directory and its name is MERGE.bin. ⚫ Do not remove the USB cable from BYOD during the firmware upgrade. ⚫ Firmware upgrade process takes around up to 90 seconds until reboot. ⚫... -
Page 14: Panel Drawing
Multiformat Presentation Switcher 6. Panel Drawing 1080P SERVICE RES. DC 24V 135.00 mm USB - C DP full sized HDMI A HDMI type-D... -
Page 15: Troubleshooting & Maintenance
Multiformat Presentation Switcher 7. Troubleshooting & Maintenance Problems Potential Causes Solutions Color losing or no video signal output in HDMI display. The connecting Check whether the cables No HDMI signal output in the cables may not be are broken or connected device while local HDMI input is connected correctly or correctly and in working... -
Page 16: Customer Service
Multiformat Presentation Switcher 8. Customer Service The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. 1) Warranty The limited warranty period of the product is fixed three years. 2) Scope These terms and conditions of Customer Service apply to the customer service provided for the products or any other items sold by authorized distributor only.
