- Page 1 User Manual SCAM62T 6x2 4K Presentation Switcher with Matrix Outputs All Rights Reserved Version: SCAM62T_2018V1.1 Altimium www.altimium.com...
- Page 2 Any changes or modifications not expressly approved by the manufacture would void the user’s authority to operate the equipment. Altimium www.altimium.com...
- Page 3 Unplug the power cord when left unused for a long period of time. Information on disposal for scrapped devices: do not burn or mix with general household waste, and please treat them as normal electrical wastes. Altimium www.altimium.com...
-
Page 4: Table Of Contents
7.2.2 Signal Switching ..................17 7.2.3 Preset Setting ..................18 7.2.4 Audio Setting ..................19 7.2.5 VGA Scaling Resolution Setting ............24 7.2.6 EDID Configuration ................25 7.2.7 HDCP Compliance ................26 7.2.8 Control Far-end Device ................. 27 Altimium www.altimium.com... - Page 5 8.5 Input Tag Setting ....................32 8.6 RS232 Control ....................33 8.7 Network Setting ....................34 8.8 Password Setting ..................... 34 8.9 GUI Update...................... 35 9. Panel Drawing ......................36 10. Troubleshooting & Maintenance ................37 11. Customer Service ....................38 Altimium www.altimium.com...
-
Page 6: Product Introduction
6x2 4K Presentation Switcher with Matrix Outputs 1. Product Introduction The SCAM62T is a 6 input multi-format (3 HDMI, 2 VGA, and 1 DP) 4K presentation switcher that switches video signals to an HDMI and an HDBaseT output. The HDBaseT output supports PoH and can connect to a compatible HDBaseT receiver up to a maximum of 70 meters (230 feet) (HDBaseT receiver sold separately). -
Page 7: Package List
Controllable via front panel buttons, IR Remote, RS232 & GUI. Supports online software upgrading. 1.2 Package List 1 x SCAM62T 6x2 4K Presentation Switcher 2 x Mounting Ears with 6 Screws 4 x Plastic Cushions 1 x IR Receiver (5V with carrier wave) -
Page 8: Specification
(1) Stereo analog audio (AUDIO 3); Output (1) Digital optical audio (AUDIO 3); (1) Power amplifier (2) 3-pin phoenix connectors; (1) 5-pin phoenix connector; (1) 3.5mm stereo jack; Output Connector (1) SPDIF; (1) 4-pin/5 mm phoenix connector Output Analog Audio Format Altimium www.altimium.com... - Page 9 HDBT OUT: 1080p≤70m; 4Kx2K≤40m Transmission Distance Operation Temperature 0 ~ +40℃ Storage Temperature -10 ~ +55℃ Relative Humidity 10% ~ 90% External Power Supply 100V~240V AC, 50/60Hz Power Consumption 40W (Max) Dimension (W*H*D) 436.4mm x 44mm x 236.5mm Net Weight 2.4kg Altimium www.altimium.com...
-
Page 10: Panel Description
⑧ MIC-: Microphone input volume down adjuster or down key for query menu. ⑨ VOL-: MASTER volume down or left key for navigation menu. ⑩ VOL+: MASTER volume up or right key for navigation menu. Note: The MASTER volume indicates all audio outputs volume. Altimium www.altimium.com... -
Page 11: Rear Panel
RS232: Serial port, 3-pin phoenix connector, connect with a control device (such as PC) to control the switcher or other third-party device connected with HDBaseT receiver. TCP/IP: Ethernet port, connect with PC to control the switcher via GUI. Altimium www.altimium.com... - Page 12 6x2 4K Presentation Switcher with Matrix Outputs ⑥ AMPLIFIER: 4/8 Ohm speaker outputs. ⑦ AC100V~240V: Power port, connect to an AC 100V~240V power via the included power cord. Altimium www.altimium.com...
-
Page 13: System Connection
MONO D efault STEREO BRIDGE 2x20W@4Ω LINE AUDIO 1 AUDIO 2 AUDIO 3 EDID FIRMWARE IR IN RS232 TCP/IP 1-HDMI 2-HDMI 3-HDMI 4-DP 5-VGA AUDIO 6-VGA AUDIO 1-HDMI 2-HDBT INPUT OUTPUT AMPLIFIER Receiver Apple TV Laptop Speaker Speaker Altimium www.altimium.com... -
Page 14: Speaker Wiring
6x2 4K Presentation Switcher with Matrix Outputs 4.3 Speaker Wiring 4.3.1 Stereo and Mono Options 4Ω Load with 4Ω Speakers: 4.3.2 Bridged Audio Option 8Ω Load with 8Ω Speakers: Altimium www.altimium.com... -
Page 15: Button Control
If the last displayed signal is still available, the unit will output the signal. If not, the unit will detect all the input signals with priority from Altimium www.altimium.com... -
Page 16: Vga Scaling Resolution Selection
Up or Down key to turn previous or next page. In Link Info In 01 02 03 04 05 06 Out Link info Connect Y N N N Connect N N In Link Info Out Link info Connect Y N Altimium www.altimium.com... -
Page 17: Embedded Edid Invoking
1080p 3D PCM 2CH AUDIO 0011 1080p 2D PCM 2CH AUDIO 0100 1080i 3D PCM 2CH AUDIO DIP Switcher 0101 1080i 2D PCM 2CH AUDIO 0110 4K PCM 2CH AUDIO Enable RS232 or GUI control 1111 mode to set EDID. Altimium www.altimium.com... -
Page 18: Ir Remote Control
Enable/disable link status query menu. ⑧ Exit button: Exit link status query menu or current operation. ⑨ 1-HDMI: Turn on/off HDMI output. ⑩ 2-HDBT: Turn on/off HDBT output. ⑪ BLACK: Press BLACK + 1-HDMI/2-HDBT to output black screen. Altimium www.altimium.com... -
Page 19: Rs232 Control
First to connect the switcher with all input devices and output devices needed, then to connect it with a computer which is installed with RS232 control software. Double-click the software icon to run this software. Here we take the software CommWatch.exe as example. The icon is shown as below: Altimium www.altimium.com... - Page 20 Monitoring area, indicates if the command sent works. Command Sending area Please set the parameters of COM number, bound rate, data bit, stop bit and the parity bit correctly, and then you are able to send command in Command Sending Area. Altimium www.altimium.com...
-
Page 21: Rs232 Communication Command
Data bit: 8 Stop bit: 1 Parity bit: none 7.2.1 System Command Command Example Command Description and Response /*Type; /*Type; Report system model. SCAM62T /%Lock; /%Lock; Lock front panel buttons. System Locked! /%Unlock; /%Unlock; Unlock front panel buttons. System UnLock! /^Version; /^Version;... -
Page 22: Signal Switching
Report the IP address. IP:192.168.0.178 %0911. Factory Default V1.0.1 %0911. Reset to factory default. System UnLock! IP:192.168.0.178 LCD 2: SCAM62T LCD 1: HDBaseT Matrix 7.2.2 Signal Switching Command Example Command Description and Response Automatically switch input source to HDMI Auto. HDMI Auto. -
Page 23: Preset Setting
Command Example Command Description and Response Store the current switching status to Save3. Save[y]. present [y]. y=0~ 9. Save To F3 Recall9. Recall[y]. Recall present [y]. y=0~ 9. Recall From F9 Clear9. Clear[y]. Clear the present [y]. Clear F9 Altimium www.altimium.com... -
Page 24: Audio Setting
Set the volume of audio output 2 to SetOut2Vol:70. SetOut2Vol: xxx. xxx (0~100). Volume of Out2 :70. Out2Volume+. Out2Volume+. The volume of audio output 2 +1. Volume of Out2 :71. Out2Volume-. The volume of audio output 2 -1. Out2Volume-. Altimium www.altimium.com... - Page 25 Mute HDBT audio output volume. BtOut Mute. BtOutUnmute. Unmute HDBT audio output volume. BtOut Unmute. Set the delay time [y] for audio output DelayTime/[x]:[y]. DelayTime/3:200. [x]. x= 1~6, y=0~2000ms. [x]Mix[y]. Switch audio input [x] to audio output 4Mix2. Altimium www.altimium.com...
- Page 26 Out2 Unmute. Out3 Unmute. Amp Unmute. %9978. Get all audio status. HdOut Unmute. BtOut Unmute. Volume of MIC : 48. Volume of LINE : 61. Volume of MASTER : Volume of Out1 : 50. Volume of Out2 : 50. Altimium www.altimium.com...
- Page 27 Get audio output 3 mute status. Out3 Mute. Out3 Unmute. %9927. %9927. Get amplifier mute status. Amp Mute. Amp Unmute. %9928. %9928. Get the microphone audio volume. Volume of MIC : 80. %9929. Get the line audio volume. %9929. Altimium www.altimium.com...
- Page 28 Volume of HdOut : 80. %9936. %9936. Get the audio volume of HDBT output. Volume of BtOut : 80. %9937. %9937. Get HDMI output mute status. HdOut Mute. HdOut Unmute. %9938. %9938. Get HDBT output mute status. BtOut Mute. BtOut Unmute. Altimium www.altimium.com...
-
Page 29: Vga Scaling Resolution Setting
1360x768 1920x1080 1920x1200 %9965. %9965. Get the 5-VGA input resolution. Resolution In 5 1920x1080 %9966. %9966. Resolution Get the 6-VGA input resolution. In 6 1920x1080 %9976. Resolution %9976. Get the output resolution. Out 1 1920x1080 Out 2 1920x1080 Altimium www.altimium.com... -
Page 30: Edid Configuration
EDID The source device obtains its EDID from HDBT output. EDIDIN/1/0. The source device EDIDIN/[x]/[y]. EDIDIN/1/0 obtains its EDID from HDMI output. 1080p 3D PCM 2CH 1080p 2D PCM 2CH 1080i 3D PCM 2CH 1080i 2D PCM 2CH Altimium www.altimium.com... -
Page 31: Hdcp Compliance
HDCP N N %9974. %9974. Get the HDCP status of output ports. Out 01 02 HDCP Y Y %9968. Out 1 is HDCP Auto Get the management mode of output %9968. Mode. ports. Out 2 is HDCP Auto Mode. Altimium www.altimium.com... -
Page 32: Control Far-End Device
RS232 pass-through function. ① x = 1~7 is for baud rate. Baud Rate 2400 4800 /-1/[X]:98 0A fe. /-1/[x]:** ** **. 9600, 98 0A fe 19200 38400 57600 115200 ② ***** is for HEX data (max 48 Byte). Altimium www.altimium.com... -
Page 33: Gui Control
In addition to control the switcher via front panel button, IR remote and RS232 communication software. The switcher can be controlled via GUI. It allows users to interact with the switcher through graphical icons and visual indicators. Type 192.168.0.178 in your browser, it will enter the log-in webpage shown as below: Altimium www.altimium.com... -
Page 34: Video Switching
HDMI OUTPUT: Switch 1-HDMI, 2-HDMI, 3-HDMI, 4-DP, 5-VGA or 6-VGA input to HDMI output. HDBT OUTPUT: Switch 1-HDMI, 2-HDMI, 3-HDMI, 4-DP, 5-VGA or 6-VGA input to HDBT output. AUTO: Enable/disable auto switching mode. Altimium www.altimium.com... -
Page 35: Vga Scaling Resolution Selection
6x2 4K Presentation Switcher with Matrix Outputs 8.2 VGA Scaling Resolution Selection Click Resolution to enter the section for selecting VGA resolution. 1024x768, 1280x720, 1280x800, 1360x768, 1920x1080, or 1920x1200 can be selected for port 5-VGA and port 6-VGA. Altimium www.altimium.com... -
Page 36: Audio Switching And Volume Adjustment
LINE/MIC: Volume control for line or microphone input. MASTER Volume: Volume control for all audio outputs. MIX: Audio matrix for switching de-embedded HDMI audio, de-embedded HDBT audio, LINE or MIC audio to audio outputs. Volume: Volume control for audio outputs. Altimium www.altimium.com... -
Page 37: Edid Management
6x2 4K Presentation Switcher with Matrix Outputs 8.4 EDID Management Click EDID to enter the section for invoking embedded EDID to HDMI and DP inputs. 8.5 Input Tag Setting Click Tags to enter the section for renaming input ports. Altimium www.altimium.com... -
Page 38: Rs232 Control
4800, 9600, 19200, 38400, 57600 or 115200. Command: Typing commands in this box to control the switcher or the far-end third-party device connected to HDBaseT receiver. If check the “Hex”, you can type RS232 commands with hexadecimal value in the “Command” box. Altimium www.altimium.com... -
Page 39: Network Setting
Click Network to enter the section for network setting. The IP address, subnet mask and gateway can be reset on the static mode. 8.8 Password Setting Click Password to enter the section to reset password and lock or unlock front panel buttons. Altimium www.altimium.com... -
Page 40: Gui Update
After that, click Administration at the source menu to get to Upload Program as shown below: Select the update file and click Apply button, it will start upgrading then. Altimium www.altimium.com... -
Page 41: Panel Drawing
ON OFF STEREO BRIDGE 2x20W@4Ω LINE AUDIO 1 A UDIO 2 AUDIO 3 EDID FIRMWA RE IR IN RS 232 TCP/ IP 1-HDMI 2-HDMI 3-HDMI 4-DP 5-V GA AUDIO 6-V GA AUDIO 1-HDMI 2-HDB T INPUT OUTPUT AMPLIFIER Altimium www.altimium.com... -
Page 42: Troubleshooting & Maintenance
The front panel buttons are to unlock the front panel while can control it through locked. buttons. RS232 port Note: If your problem still remaining after following the above troubleshooting steps, please find further assistance. Altimium www.altimium.com... -
Page 43: Customer Service
Remarks: For further assistance or solutions, please contact your local distributor. Altimium www.altimium.com... - Page 44 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
