- Page 1 User Manual SCA61TS 6-input Seamless Scaler Switcher & HDBaseT Receiver All Rights Reserved Version: SCA61TS_2017V1.2...
- Page 2 Any changes or modifications not expressly approved by the manufacture would void the user’s authority to operate the equipment. Altimium www.altimium.com...
- Page 3 Unplug the power cord when left unused for a long period of time. Information on disposal for scrapped devices: do not burn or mix with general household waste, please treat them as normal electrical wastes. Altimium www.altimium.com...
-
Page 4: Table Of Contents
6.3.1 RS232 Control Mode Switching ............. 17 6.3.2 Input Signal Switching ................17 6.3.3 Audio Adjusting ..................18 6.3.4 VGA Scaling Configuration ..............20 6.3.5 Output Image Adjusting ................. 20 6.3.6 Auto Power-off Setup ................22 6.3.7 OSD Menu Control ................23 Altimium www.altimium.com... - Page 5 8.4 Password Menu ....................35 8.5 GUI Update ...................... 35 9. Specification ......................36 9.1 Seamless Scaler Switcher ................36 9.2 HDBaseT Receiver ..................37 10. Panel Drawing ......................38 11. Troubleshooting & Maintenance ................39 12. Customer Service ....................40 Altimium www.altimium.com...
-
Page 6: Introduction
Bi-directional IR & RS232 control. Supports CEC. Supports MHL. Output resolutions selectable to assure preferred output, and supports various output resolutions, such as 1920x1200, 1920x1080, 1600x1200, 1600x900, 1360x768, 1280x800, 1280x720, 1024x768. Supports online software upgrading. Altimium www.altimium.com... -
Page 7: Package List
6-input Seamless Scaler Switcher & HDBaseT Receiver 1.3 Package List 1 x SCA61TS(NR) Seamless Scaler Switcher 2 x Mounting Ears with 4 Screws 2 x Long Mounting Ears with 6 Screws (Optional) 1 x Power Adapter (24VDC,2.71A) ... -
Page 8: Panel Description
Note: When you set any VGA port to C-video or YPbPr in Manual-switching mode, the system will not be able to enter Auto-switching mode. ⑩ Volume knob for variable audio control- Push knob in to toggle between ‘MIX’ and ‘Source’ control. Altimium www.altimium.com... - Page 9 PC) to control the Scaler Switcher or other devices connected with HDBaseT Receiver. TCP/IP: Ethernet port, connect with PC to control the Scaler Switcher via GUI. ⑤ AUDIO OUT - Stereo balanced L/R audio output. ⑥ DC 24V - Locking power port, connect 24V DC power adapter. Altimium www.altimium.com...
-
Page 10: Hdbaset Receiver
② Link status LED - OFF: No Link / GREEN: Link successful. ③ HDCP compliant LED - OFF: No HDMI traffic/GREEN: Traffic with HDCP/Blinking GREEN: Traffic without HDCP. ④ Power LED - RED when device is powered on and no indicator when there is no power to device. Altimium www.altimium.com... - Page 11 ⑧ HDBT IN - Connect to the HDBT OUT socket on HDBaseT Transmitter or Matrix Switcher via CAT5e/6a/7 cable, support unidirectional PoH technology. ⑨ DC 12V power port - Connect to 12VDC power adaptor, or it can be powered via the Scaler Switcher by PoH technology. Altimium www.altimium.com...
-
Page 12: System Connection
2-AUDIO IR IN IR OUT IR EYE RS232 TCP/IP DC 24V HDBT Ethernet: 1-HDMI/MHL 2-HDMI 3-HDMI 4-HDMI 5-DP 6-VGA HDMI HDBaseT: IR Control: INPUTS OUTPUTS IR Emitter HDBaseT Receiver Laptop MacBook DVD Remote IR Receiver IR Emitter Projector Altimium www.altimium.com... -
Page 13: Connection Procedure
Connect DC24V power adaptor to the power port (HDBaseT Receiver can be powered by the Scaler Switcher with PoH function). Note: If the power adapter is connecting with HDBaseT Receiver, the Scaler Switcher can’t be powered from HDBaseT Receiver. Altimium www.altimium.com... -
Page 14: Button Control
4.3 Volume Adjusting Press Volume knob to select MIX or Source audio to adjust, the corresponding LED will turn green and keep on, and then move the volume knob in clockwise or anti-clockwise direction to turn up/down sound volume. Altimium www.altimium.com... -
Page 15: Ir Control
Auto button: Enter/Exit auto-switching mode. ⑥ OK: confirm button; Navigation buttons: UP/DWON/LEFT/ RIGHT button, for value setting or page-turn. ⑦ Exit button: Exit OSD menu or current operation. ⑧ Enter OSD menu or return to previous menu. Scaler Switcher Altimium www.altimium.com... -
Page 16: Control Far-End Display Device
IR Receiver HDMI: HDBaseT: IR Control: AUDIO IN CONTROL AUDIO OUT POWER 1-AUDIO 2-AUDIO IR IN IR OUT IR EYE RS232 TCP/IP DC 24V HDBT 1-HDMI/MHL 2-HDMI 3-HDMI 4-HDMI 5-DP 6-VGA HDMI INPUTS OUTPUTS HDBaseT Receiver IR Emitter Projector Altimium www.altimium.com... -
Page 17: Control Local Source Device
Commands pertaining to CEC: “50686%” (enable CEC) and “50687%” (disable CEC) HDMI INPUT ports support CEC, if the connected source devices also support CEC and their CEC are on, users can control the source device and display via the IR Remote of the Scaler Switcher. Altimium www.altimium.com... - Page 18 CEC: on, Standby: off enters in standby mode, HDMI source devices and display keep on. buttons on IR CEC: on Remote to control HDMI source device. Unable to control HDMI source device and display through IR CEC: off Remote Altimium www.altimium.com...
-
Page 19: Rs232 Control
RS232: HDBaseT: Laptop AUDIO IN CONTROL AUDIO OUT POWER 1-AUDIO 2-AUDIO IR IN IR OUT IR EYE RS232 TCP/IP DC 24V HDBT 1-HDMI/MHL 2-HDMI 3-HDMI 4-HDMI 5-DP 6-VGA HDMI INPUTS OUTPUTS HDBaseT Receiver Third-party device Altimium www.altimium.com... -
Page 20: Installation/Uninstallation Of Rs232 Control Software
Basic Settings: First to connect the Scaler Switcher with all input devices and output devices needed, then to connect it with a computer which is installed with RS232 control software. Double-click the software icon to run this software. Altimium www.altimium.com... - Page 21 Monitoring area, indicates if the command sent works. Command Sending area Please set the parameters of COM number, bound rate, data bit, stop bit and the parity bit correctly, and then you are able to send command in Command Sending Area. Altimium www.altimium.com...
-
Page 22: Rs232 Communication Commands
Input 6 Set & Switch to 50681% input. YPbPr Set the signal format to AV(C-video) for Input 6 Set & Switch to AV 50682% 6-VGA input. Input: xx (xx= HDMI1/ Get the input source. HDMI2/ HDMI3/ HDMI4/ 50631% DP/VGA/ YPbPr/ AV) Altimium www.altimium.com... -
Page 23: Audio Adjusting
Disable VGA audio. VGA Audio Mute Enable VGA audio. VGA Audio Unmute 50727% VGA Audio Mute/VGA Audio 50712% Get the audio input sources for VGA. Unmute Disable 1-HDMI audio. HDMI1 Audio Mute 50660% 50661% Enable 1-HDMI audio. HDMI1 Audio Unmute Altimium www.altimium.com... - Page 24 MIX Disable/MIX Enable 1-AUDIO Disable/1-AUDIO Check external audio input status (MIX, 50947% Enable 1-AUDIO, 2-AUDIO). 2-AUDIO Enable/2-AUDIO Enable Embedded Audio Output: 50648% Enable HDMI embedded audio output. enable Embedded Audio Output: Disable HDMI embedded audio output. 50649% disable Altimium www.altimium.com...
-
Page 25: Vga Scaling Configuration
Set the contrast to xx. Contrast: xx (xx=00~99) 503xx% 50637% Get the contrast. Contrast: xx (xx=00~99) 504xx% Set the saturation to xx. Saturation: xx (xx=00~99) Get the saturation. Saturation: xx (xx=00~99) 50638% 505xx% Set the sharpness to xx. Sharpness: xx (xx=00~99) Altimium www.altimium.com... - Page 26 Get the Icon status. Icon: disable Freeze Icon: enable/Freeze Icon: disable 50651% Get Volume Icon display status. Volume Icon: xxxx Auto-adjust the input parameter(VGA 50606% VGA Input Auto only) 50678% Enable screen output adjusting. Enter Output Position Adjust Altimium www.altimium.com...
-
Page 27: Auto Power-Off Setup
Auto Switch Mode: Set the auto power-off 50717% Auto power off: 5min time to 5 minute when No signal input. Auto Switch Mode: Set the auto power-off Auto power off: 10min 50718% time to 10 minute when No signal input. Altimium www.altimium.com... -
Page 28: Osd Menu Control
Feedback Example 50686% Enable CEC Input. HDMI CEC ON Disable CEC Input. HDMI CEC OFF 50687% Play & pause. CEC cmd: play&pause 50901% 50902% Stop. CEC cmd: stop Menu. CEC cmd: menu 50903% Reverse. CEC cmd: rev 50904% Altimium www.altimium.com... -
Page 29: Cec Output Commands
Power off output display device. Display Power Off 50923% 6.3.10 EDID Configuration Command Function Feedback Example Set 1-HDMI/MHL EDID to 720P. HDMI1 EDID:720P 50731% Set 1-HDMI/MHL EDID to 1080P. HDMI1 EDID to:1080P 50732% Set 1-HDMI/MHL EDID to 1920x1200. HDMI1 EDID to:1920x1200 50733% Altimium www.altimium.com... -
Page 30: Hdcp Compliance
HDMI Resolution:1920x1080 input. 6.3.11 HDCP Compliance Command Function Feedback Example HDCP Active mode. HDCP Active. 50791% HDCP Manual mode. HDCP Manual. 50792% HDCP Active/HDCP Manual Get HDCP status. 50795% HDCP ON/HDCP OFF Altimium www.altimium.com... -
Page 31: Device Setup
Line Volume:XX (Line xx = 00 to 60) Input:XXXX Get current status Resolution:XXXX Display status including Source, Line 50783% Embedded Audio Output: audio, Resolution, Output Audio on/off, XXXX(Enable/Disable) Manual/ Auto-switching modes Source Mute/Source Unmute Line Mute/Line Unmute Auto Switch/Manual Switch VGA Mute/Unmute Altimium www.altimium.com... -
Page 32: Osd Menu Control
Includes output adjust, input selection, baud rate, user EDID load (USB), resolution, and software update (USB). Output Adjust: Adjust output image position (X: horizontal direction and Y: vertical direction), ratio aspect (width and height), polarity adjustment (H Polarity and V Altimium www.altimium.com... -
Page 33: Picture
Color Temperature: Include Cool, Medium, Warm and User. And only in User mode, it is able to set values for Red, Green and Blue (RGB). Altimium www.altimium.com... -
Page 34: Setup
Restore Factory Default: Restores to original system state. HDMI CEC: Enable/disable CEC and auto-standby function. Default: CEC on, STANDBY on. Only when CEC is on, will it be able to set auto-standby status. FW Ver. 1.0.0: Software version. Altimium www.altimium.com... -
Page 35: Gui Control
The Scaler Switcher can be controlled via GUI. It allows users to interact with the Scaler Switcher through graphical icons and visual indicators. Type 192.168.0.178 in your browser, it will enter the log-in interface shown as below: Altimium www.altimium.com... -
Page 36: Control Menu
Standby: Click this button to let the Scaler Switcher into standby mode. Volume: Click the corresponding positive/negative button or move the scroll bar to turn up/down the MIX/Source audio volume. Click the corresponding Mute button to mute/unmute Line/Source audio input. Altimium www.altimium.com... -
Page 37: Configuration Menu
Shutdown Timer(NO Input)：Set the auto power-off time or manual power-off time, including none, 1 minute, 2minutes, 5minutes and 10 Minutes. If the Scaler Switcher can’t detect video source input, it will automatically shut down after a preset interval. Altimium www.altimium.com... - Page 38 Click Network to enter the below menu to select the dynamic or static mode. Under static mode, then IP address, subnet mask and gateway can be reset. ③ Source Click Source Label to enter the below menu to rename the input selection buttons. Altimium www.altimium.com...
-
Page 39: Rs232 Control Menu
4800、9600、19200、38400、57600、115200. Command: Typing commands in this box to control the Scaler Switcher or the far-end third-party device connected to HDBaseT Receiver. If check the “Hex”, you can type RS232 commands with hexadecimal value in the “Command” box. Altimium www.altimium.com... -
Page 40: Password Menu
After that, click Administration at the source menu to get to Upload Program as shown below: Select the desired update file and press Apply, it will start upgrading then. Altimium www.altimium.com... -
Page 41: Specification
(1)3-Pin phoenix connectors; (1) RJ45 General 1080P≤70m Transmission Distance Temperature -10℃ ~ +50℃ Humidity 10% ~ 90% Power Supply Input: AC 100~240V, 50/60Hz; Output: 24VDC 2.71A Power Consumption 28W (Max) Dimension (W*H*D) 250mm x 44mm x 200mm Weight 970g Altimium www.altimium.com... -
Page 42: Hdbaset Receiver
Resolution Up to 4K×2K@60Hz 4:2:0 Bandwidth 10.2Gbps HDMI Standard HDMI1.4 & HDCP2.2 Power Consumption 10W (max) Temperature -10℃~ 50℃ Humidity 0% ~ 90% Power Supply Powered by the Seamless Scaler Switcher Dimension (W*H*D) 152mmx16.2mmx100mm Net Weight (g) 223g Altimium www.altimium.com... -
Page 43: Panel Drawing
6-input Seamless Scaler Switcher with HDBaseT 250 mm 1-HDMI/MHL 2-HDMI 3-HDMI 4-HDMI 5-DP 6-VGA AUTO SOURCE ENTER MENU/3s RES RESET/3s VOLUME 10-1 Seamless Scaler Switcher TPUH412RA 152 mm UPDATE B UPDATE A LINK HDCP CTRL 10-2 HDBaseT Receiver Altimium www.altimium.com... -
Page 44: Troubleshooting & Maintenance
Cannot control the device The device has already Send it to authorized by RS232 / IR remote / been broken. dealer for repairing. front panel buttons If your problem still remaining after following the above troubleshooting steps, please find further assistance. Altimium www.altimium.com... -
Page 45: Customer Service
Remarks: For further assistance or solutions, please contact your local distributor. Altimium www.altimium.com... - Page 46 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
