- Page 1 User Manual SCA61E Compact Scaler Switcher 6x1 All Rights Reserved Version: SCA61E_2016V1.0...
- Page 2 Any changes or modifications not expressly approved by the manufacture would void the user’s authority to operate the equipment. Altimium www.altimium.com...
- Page 3 Unplug the power cord when left unused for a long period of time. Information on disposal for scrapped devices: do not burn or mix with general household waste, please treat them as normal electrical wastes. Altimium www.altimium.com...
-
Page 4: Table Of Contents
Compact Scaler Switcher 6x1 Contents 1. Introduction ......................... 1 1.1 Introduction to SCA61E ..................1 1.2 Features ......................1 1.3 Package List ...................... 1 2. Panel Description ......................3 2.1 Front Panel ......................3 2.2 Rear Panel ......................4 3. System Connection ..................... 5 3.1 Usage Precautions .................... -
Page 5: Introduction
1. Introduction 1.1 Introduction to SCA61E SCA61E is a compact 6x1 mini unit with 6 video inputs (4 HDMI, 2 VGA), 2 auxiliary audio inputs (switched following VGA), 1 HDMI output and 3 audio outputs (1 dual-mono analog audio, 1 3.5mm stereo audio, 1 optical audio). - Page 6 Compact Scaler Switcher 6x1 1 x User manual Notes： Confirm all the accessories are included, if not, please contact with the dealers. Altimium www.altimium.com...
-
Page 7: Panel Description
Press to switch on/off audio & Video output. All LED turn off ⑦ OUTPUT BLACK except power LED when switch off output. Note: Pictures shown in this manual are for reference only, different model and specifications are subject to real product. Altimium www.altimium.com... -
Page 8: Rear Panel
IR IN: connect to an IR Receiver, to receive IR signal send by corresponding IR remote. ④ DC 5V Connect to a DC 5V 3A power adapter. Note: Pictures shown in this manual are for reference only, different model and specifications are subject to real product. Altimium www.altimium.com... -
Page 9: System Connection
Step1. Connect HDMI/DVI sources (e.g. DVD) to HDMI input ports of SCA61E with HDMI cables. Step2. Connect VGA sources (e.g. DV Camera) to VGA input ports of SCA61E with VGA cables. Step3. Connect sources to the AUDIO input ports of SCA61E with audio cables. -
Page 10: Application
Step8. Plug DC 5V 3A power adapter to Compact Scaler Switcher. 3.4 Application SCA61E has a good application in various occasions, such as computer realm, monitoring, conference room, big screen displaying, television education, command & control center and smart home etc. -
Page 11: System Operations
If the last displayed signal is still available, SCA61E will output the signal. If not, the unit will detect all the inputs signals with priority from HDMI1 to VGA2. When detected the first signal, it will transfer to output. -
Page 12: Rs232 Control
Uninstallation Delete all the control software files in corresponding file path. 4.2.2 Basic Settings Firstly, connect SCA61E with an input device and an output device. Then, connect it with a computer which is installed with RS232 control software. Double-click the software icon to run this software. -
Page 13: Rs232 Communication Commands
Switch to HDMI 4 Input Switch to HDMI 4 50705% Switch to VGA 1 input Switch to VGA 1 50706% Switch to VGA 2 input Switch to VGA 2 50785% Enable auto-switching Auto Switching 50786% Disable auto-switching Manual Switching Altimium www.altimium.com... - Page 14 Set the picture mode for VGA input dynamic/ standard/ mild/ 50614% user) Sound Mode: xx Sound Mode: xx (xx= 50615% Set SM audio mode for VGA input standard/ music/ movie/ sports/ user) Embedded Audio Output: 50648% Enable HDMI embedded audio output enable Altimium www.altimium.com...
- Page 15 EDID:4K&PCM 2ch 4K&PCM 2ch EDID:user 50787% Set the EDID date of all input ports: user Output black:enable 50653% Switch off audio & video output Output black:disable 50654% Switch on audio & video output Switch to VGA2 Inquire Commands Altimium www.altimium.com...
- Page 16 Pull right from left side (decrease image 50675% Output Width Adjust xx width) Stretch upwards from top side (increase 50676% Output Height Adjust xx image height) Stretch downwards from top 50677% Output height adjust xx side(decrease image height) Altimium www.altimium.com...
- Page 17 Step1. Copy the file( the file must be named EDID.bin) to the root directory of a USB flash disk. Step2. Plug the USB flash disk to the Firmware port on its rear panel. Step3. Send command 50769% to read EDID data from U flash disk, then, send command 50787% to update EDID. Altimium www.altimium.com...
-
Page 18: Ir Control
Press to switch on/off Audio& Video output 4.4 Firmware Updating SCA61E supports firmware updating via USB flash disk. The procedures as follows: Step1. Copy the file “MERGE.bin” to the root directory of a USB flash disk. (Make sure the file is copied to the root directory for normal use. The “MERGE.bin” file is provided/ authorized. -
Page 19: Specification
Weight 0.63Kg (W*H*D) Reference Temperature 0℃ ~ 50℃ 10% ~ 90% Humidity Transmit 4Kx2K≤15m Distance Note: SCA61E supports 4k&1080p 3D HDMI signal, please adopt quality HDMI cables compliant with HDMI1.4 for reliable transmission when connecting Supported Input Resolutions Altimium www.altimium.com... - Page 20 1600x1200@70Hz, 1600x1200@75Hz, 1600x1200@85Hz, 1680x1050@60Hz, 1792x1344@60Hz, 1856x1392@60Hz, 1856x1392@75Hz, 1920x1080@60Hz, 1920x1200@60Hz, 1920x1440@60Hz, 3840x2160@24Hz, 3840x2160@30Hz, 3840x2160@25Hz, 4096x2160@24Hz, 4096x2160@25Hz, 4096x2160@30Hz, 800x600@60Hz, 800x600@72Hz, 800x600@75Hz, 1024x768@60Hz, 1024x768@70Hz, 1024x768@75Hz, 1280x768@60Hz, 1280x768@75Hz, 1280x960@60Hz, 1280x1024@60Hz, 1280x1024@75Hz, 1365x1024@60Hz, 1365x1024@75Hz, 1600x1024@60Hz, 1600x1200@60Hz, 1600x1200@65Hz, 1600x1200@70Hz, 1600x1200@75Hz, 1680x1050@60Hz, 1792x1344@60Hz, 1920x1080@60Hz, 1920x1200@60Hz Altimium www.altimium.com...
-
Page 21: Panel Drawing
1920x1200 SOURCE RESOLUTION OUTPUT BLACK 13.5 mm INPUTS OUTPUTS CONTROL POWER HDMI 1 HDMI 2 HDMI 3 HDMI 4 VGA 1 AUDIO 1 VGA 2 AUDIO 2 HDMI AUDIO AUDIO OPTICAL FIRMWARE RS 232 IR IN DC 5V Altimium www.altimium.com... -
Page 22: Troubleshooting & Maintenance
IR receiver receiver. Cannot control The device has already Send it to authorized dealer for device been broken. repairing. If your problem persists after following the above troubleshooting steps, seek further help from authorized dealer or our technical support. Altimium www.altimium.com... -
Page 23: After-Sales Service
Product version and name. Detailed failure situations. The formation of the cases. Remarks: For any questions or problems, please try to get help from your local distributor. Altimium www.altimium.com... - Page 24 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
