- Page 1 User Manual TP70WPBH-EU 3x1 Wallplate Transmitter Switcher with HDMI and VGA All Rights Reserved Version: TP70WPBH-EU_2019V1.0...
- Page 2 Any changes or modifications not expressly approved by the manufacture would void the user’s authority to operate the equipment. Altimium www.altimium.com...
- Page 3 Unplug the power cord when left unused for a long period of time. Information on disposal for scrapped devices: do not burn or mix with general household waste, please treat them as normal electrical wastes. Altimium www.altimium.com...
-
Page 4: Table Of Contents
6.3.4 VGA Audio Control ................. 12 6.3.5 Baud Rate Setting ................. 12 6.3.6 EDID Management ................12 6.3.7 CEC Control ..................13 6.3.8 Button User-defined ................14 7. Panel Drawing ......................15 8. Troubleshooting & Maintenance ................16 9. Customer Service ..................... 17 Altimium www.altimium.com... -
Page 5: Product Introduction
3x1 Wallplate Transmitter Switcher with HDMI and VGA 1. Product Introduction Thanks for choosing the TP70WPBH-EU 3x1 Wallplate Transmitter Switcher, which is designed to switch and extend HDMI or VGA input signal to far-end display device, and the transmission distance is up to 131ft/40m at 4K and 229ft/70m at 1080P video by using a single CATx cable. -
Page 6: Package List
3x1 Wallplate Transmitter Switcher with HDMI and VGA 1.2 Package List 1x TP70WPBH-EU 1x 2-pin Terminal Block 2x 3-pin Terminal Blocks 1x Power Adapter (24V 1.25A) 1x User Manual Note: Please contact your distributor immediately if any damage or defect in the components is found. -
Page 7: Specification
151mm x 80mm x 39mm Net Weight 245g Note: The TP70WPBH-EU also can be powered from the HDBaseT receiver which supports 48V PoH. The CAT6A cable is recommended when the TPUH412R HDBaseT receiver is chosen to be used with the TP70WPBH-EU wallplate transmitter switcher. -
Page 8: Panel Description
⑧ DISPLAY ON/OFF: Turn the display ON or OFF via CEC or RS232 (Programming required). For more details, please refer to the 5.2 Display Control on the page 8. ⑨ LINK LED: The LED illuminates green to indicate a valid data link with the HDBaseT receiver. Altimium www.altimium.com... -
Page 9: Rear Panel
RS232 pass-through. For more details, please refer to the 6. RS232 Control on the page 9. ③ DC IN: Power port to connect 24V DC power adapter. ④ IR IN: 3-pin terminal block to connect an IR receiver. Altimium www.altimium.com... -
Page 10: Side Panel
3x1 Wallplate Transmitter Switcher with HDMI and VGA 3.3 Side Panel ① FIRMWARE: Micro-USB port for firmware upgrade. Altimium www.altimium.com... -
Page 11: System Connection
The following diagram illustrates typical input and output connection that can be utilized with the switcher: Receiver Remote Power In Projector VGA: HDMI: Laptop Blu-ray Audio: Power: RS232: HDBaseT: Projector Screen Note: We recommend CATx cabling with alien crosstalk prevention technology to ensure the performance of HDBaseT link. Altimium www.altimium.com... -
Page 12: Button Control
1) Press the DISPLAY ON/OFF button to turn on/off the display. 2) If the incompatible display device needs to be used with this switcher, the DISPLAY ON/OFF button can be programed by RS232 command. For more details, please refer to the 6.3.8 Button User-defined on the page 14. Altimium www.altimium.com... -
Page 13: Rs232 Control
② When control the far-end third party device from local control device (e.g. PC), connect the PC to the RS232 port of the switcher, and then connect the third party device (e.g. projector) to the RS232 port of receiver. The connection diagram shown as below: Receiver Power In Projector Altimium www.altimium.com... -
Page 14: Rs232 Control Software
Uninstallation: Delete all the control software files in corresponding file path. Basic Settings: Connect TP70WPBH-EU with all input devices and output devices needed, then to connect it with a computer which is installed with RS232 control software. Double-click the software icon to run this software. -
Page 15: Rs232 Command
50714% Auto adjust VGA Input. Enable VGA AUTO ADJUST 50715% 1024x768@60Hz. RESOLUTION: 1024x768 60Hz 50716% 1280x720 @50Hz. RESOLUTION: 1280x720 50Hz 50717% 1280x720 @60Hz. RESOLUTION: 1280x720 60Hz 50718% 1360x768 @60Hz. RESOLUTION: 1360x768 60Hz 50719% 1600x1200 @60Hz. RESOLUTION: 1600x1200 60Hz Altimium www.altimium.com... -
Page 16: Vga Audio Control
4K@30Hz 2D PCM 2CH. EDID:4K30, 2D 2CH 50772% 1280x720@60Hz DVI. EDID:1280x720@60, DVI 50773% 1920x1080@60Hz DVI. EDID:1920x1080@60, DVI 50774% 1280x720@60Hz PCM 2CH. EDID:1280x720@60 50775% 1280x800@60Hz PCM 2CH. EDID:1280x800@60 50776% Get the TV EDID. GET TV EDID 50777% Select default EDID. EDID:INITIAL Altimium www.altimium.com... -
Page 17: Cec Control
CEC commands. Command Function Feedback Example 50733% Display on. CEC DISPLAY ON 50734% Display off. CEC DISPLAY OFF Send CEC command “xx:xx:xx…” CEC <xx:xx:xx…> <xx:xx:xx... to control display device. .> Altimium www.altimium.com... -
Page 18: Button User-Defined
HEX characters 30 31 32 33. b=4, Baud rate is 38400 b=5, Baud rate is 57600 b=6, Baud rate is 115200 SET TIME TO xxx MINUTES Set the booking shutdown time to /x0:xxx TO TURN OFF THE DISPLAY IF xxx. NO SOURCE DETECTED Altimium www.altimium.com... -
Page 19: Panel Drawing
3x1 Wallplate Transmitter Switcher with HDMI and VGA 7. Panel Drawing 151.00 mm 70.00 mm 3.00 mm 39.10 mm 108.60 mm lower level 39.1mm 26.2mm Altimium www.altimium.com... -
Page 20: Troubleshooting & Maintenance
Ensure the power cord work or no respond to any cord connection. connection is good. operation. Note: If your problem still remaining after following the above troubleshooting steps, please contact your local dealer or distributor for further assistance. Altimium www.altimium.com... -
Page 21: Customer Service
Remarks: Please contact your local distributor for further assistance or solutions. Altimium www.altimium.com... - Page 24 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
