6.2.1 J2 – 10-pin microSD / SD connector
TE CONNECTIVITY 1-1734839-0
Pin No. Name
1 DATA BIT 1
2 DATA BIT 0
3 GND
4 CLOCK
5 POWER
6 COMMAND LINE
7 DATA BIT 3
8 DATA BIT 2
9 CARD DETECT
10 WRITE PROTECT
