5.2.3 J3 – LVDS Video Interface
KEL USL00-30L
Pin No. Name
1 LVDS DATA3 +
2 LVDS DATA3 -
3 LVDS CLK +
4 LVDS CLK -
5 LVDS DATA2 +
6 LVDS DATA2 -
7 LVDS DATA1 +
8 LVDS DATA1 -
9 LVDS DATA0 +
10 LVDS DATA0-
11 GND
12 CAM UART TX
13 CAM UART RX
14 DC OUT
15 DC OUT
16 DC OUT
17 DC OUT
18 DC OUT
19 GND
20 GND
21 N/C
22 N/C
23 N/C
24 N/C
25 N/C
26 RESET OUT
27 N/C
28 N/C
29 N/C
30 N/C
support@ionodes.com |
Comments
Connects to camera's TxD
Connects to camera's RxD
6V
6V
6V
6V
6V
Reset: Low (GND), Normal: Open (1.8V)
