DEMO MANUAL DC2227A
aDDitional information
Variables
Name Description
System Command Command Code
Definition
Device Access Standardized Device
Locks Locking Functions
Parameter (Write) Parameter Write
Access Lock Access
Data Storage Lock Data Storage
Local Local parameterization
Parameterization
Lock
Local User Local User Interface
Interface Lock Operation
Vendor Name Informative
Vendor Text Additional Vendor
Information
Product Name Detailed Product or
Type Name
Product ID Product or type
identification
Product Text Description of
Device function or
Characteristic
Serial Number Vendor Specific SN
Hardware Version Vendor Specific Format
Firmware Version Vendor Specific Format
Application Tag location or Tag
Specific Tag Function Defined by
User
Error Count Errors Since Power-
On or Reset
Light Bulb Light Bulb State
ADC Offset ADC Offset (in LSB)
(in LSB)
SC1 Counter Short Circuit Counter
on CQ1
SC2 Counter Short Circuit Counter
on Q2
Overtemp Counter Counts
Overtemperature Events
4mvK ADC Input Parameter
for Temperature
Measurement
(LTC2997's VPTAT)
1V8 ADC Input Parameter
for Temperature
Measurement
(LTC2997's V
8
Index Subindex Datatype
2 00 UIntegerT
12 00 RecordT
12 01 BooleanT
12 02 BooleanT
12 03 BooleanT
12 04 BooleanT
16 00 StringT
17 00 StringT
18 00 StringT
19 00 StringT
20 00 StringT
21 00 StringT
22 00 StringT
23 00 StringT
24 00 StringT
32 00 UIntegerT
64 00 BooleanT
65 00 IntegerT
80 00 UIntegerT
81 00 UIntegerT
82 00 UIntegerT
90 00 UIntegerT
91 00 UIntegerT
)
REF
Length Access Rights
8 Bit wo
1 Bit rw
1 Bit rw
1 Bit rw
1 Bit rw
1 Bit rw
Max. 64 Byte ro
Max. 64 Byte ro www.teconcept.de
Max. 64 Byte ro
Max. 64 Byte ro TEC-LTC DC2227A
Max. 64 Byte ro
Max. 16 Byte ro
Max. 64 Byte ro
Max. 64 Byte ro
Max. 32 Byte rw Testing*********...
16 Bit ro
1 Bit rw
8 Bit rw
16 Bit ro
16 Bit ro
8 Bit ro
12 Bit rw
12 Bit rw
Default Value Range
-
0 0 or 1
0 0 or 1
0 0 or 1
0 0 or 1
TEConcept GmbH
-
www.linear.com
LTC DC2227A -
-
TEC-LTC IO-Link -
DC2227A
-
2.0 -
1.2.5 -
-
0 0 or 1
0 –128 to 127
0 0 to 65535
0 0 to 65535
0 0 to 255
0 0 to 4095
0 0 to 4095
Unit
LSB
LSB
LSB
dc2227af
