DEMO MANUAL DC2227A
parts list
ITEM QTY REFERENCE
Push-Buttom Specific Components
1 1 R53
2 1 SW1
Additional Demo Board Circuit Components:
1 1 C21
2 0 C17
3 0 C27, C28, C29, C32
4 0 C100
5 0 D6
6 1 D7
7 0 D8
8 1 LED1
9 2 LED2, LED3
10 18 R1, R11, R13, R15, R23, R24,
R25, R27, R28, R29, R30,
R31, R32, R33, R36, R37,
R38, R39
11 2 R2, R44
12 8 R7, R19, R45, R46, R47, R48 RES, 100k, 1%, 1/10W, 0603
13 2 R21, R26
14 2 R34, R35
15 1 R41
16 0 R52
17 0 U2
18 0 Y2
Hardware-For Demo Board Only:
1 0 J1
2 1 J3
3 1 J2
4 1 J4
5 0 J5
6 1 J6
7 1 J7
8 2 J8, J9
9 5 J3, J6-J9
10 1 LP1
11 1
12 1
13 4
14 4
15 4
16 4
10
PART DESCRIPTION
RES, 4.7k, 1%, 1/10W, 0603
SWITCH, PUSHBUTTON
CAP, X5R, 100nF, 10%, 10V, 0603
OPTIONAL
OPTIONAL
OPTIONAL
OPTIONAL
DIODE, SOT23
OPTIONAL
LED, 0603D
LED, 0603D
RES, 1k, 1%, 1/10W, 0603
RES, 0Ω, 1%, 1/10W, 0603
RES, 10k 1%, 1/10W, 0603
RES, 1.8k, 1%, 1/10W, 0603
RES, 88.7k, 1%, 1/10W, 0603
OPTIONAL
OPTIONAL
OPTIONAL
OPTIONAL
HEADER, 1 × 2, 0.1"
CONNECTOR, M12, 5 PIN
HEADER 2 × 8 2mm
OPTIONAL
HEADER, 1 × 4, 0.1"
HEADER, 2 × 10, 0.1 "
HEADER, 1x3, 0.1"
SHUNT, 0.1"
SOCKET, LAMP SOCKET, WEDGE, T3 1/4
BULB, WEDGE, 28V, .1A, 1.6M
CABLE, 2M 4-WIRE UNSHIELDED
STANDOFF, 6-32 ALUM 3/8"
MACHINE SCREW, PAN PHILLIPS 6-32, 3/8"
LOCK WASHER, #6
FLAT WASHER, #6, NYLON
MANUFACTURER/PART NUMBER
VISHAY, CRCW06034K70FKEA
WÜRTH ELEKTRONIK, 430182050816
AVX, 0603ZD104KAT2A
DIODES INC., BAV199-7-F
VISHAY, VLMTG1300-GS08
KINGBRIGHT, KPG-1608SURKC-T
VISHAY, CRCW06031K00FKEA
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW0603100KFKEA
VISHAY, CRCW060310K0FKEA
VISHAY, CRCW06031K80FKEA
VISHAY, CRCW060388K7FKEA
WÜRTH ELEKTRONIK, 61300211121
BINDER, 09-3441-500-05
WÜRTH ELEKTRONIK, 62001621121
WÜRTH ELEKTRONIK, 61300411121
WÜRTH ELEKTRONIK, 61302021121
WÜRTH ELEKTRONIK, 61300311121
WÜRTH ELEKTRONIK, 60900213421
CML INNOVATIVE TECH., LH10
JKL Components, 400
BINDER, 79-5001-20-04
DIGI-KEY, 3486K-ND
KEYSTONE, 9904
KEYSTONE, 4700
KEYSTONE, 3122
dc2227af
