Kramer Electronics, Ltd.

USER MANUAL

VM-2HD
HD/SD – SDI DA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pico TOOLS VM-2HD and is the answer not in the manual?

Questions and answers

Summary of Contents for Kramer Pico TOOLS VM-2HD

  • Page 1: User Manual

    Kramer Electronics, Ltd. USER MANUAL VM-2HD HD/SD – SDI DA...
  • Page 2: Table Of Contents

    Technical Specifications Figures Figure 1: VM-2HD HD/SD - SDI DA Figure 2: Connecting the VM-2HD HD/SD - SDI DA Tables Table 1: VM-2HD HD/SD - SDI DA Features Table 2: Technical Specifications of the VM-2HD HD/SD - SDI DA Contents...
  • Page 3: Introduction

    GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors 2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com 3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com Introduction...
  • Page 4: Overview

    200m HD/SD SDI Camera Connect the power Overview The VM-2HD HD/SD - SDI DA is a high performance 1:2 distributor for all SDI video signals. In particular, the VM-2HD: Supports up to 200m Accepts one input and distributes the signal to two identical outputs using BNC connectors Has a video bandwidth of 1.485GHz that enables it to be used for standard...
  • Page 5: Your Vm-2Hd Hd/Sd - Sdi Da

    Warning before installing or removing device or servicing unit. Your VM-2HD HD/SD - SDI DA Figure 1 and Table 1 define the VM-2HD HD/SD - SDI DA: Figure 1: VM-2HD HD Table 1: VM-2HD HD/SD - SDI DA Features Feature...
  • Page 6: Connecting The Vm-2Hd Hd/Sd - Sdi Da

    Connecting the VM-2HD HD/SD - SDI DA Connecting the VM-2HD HD/SD - SDI DA To connect the VM-2HD, as the example in Figure 2 illustrates, do the following: Connect an HD-SDI/SD-SDI video source (for example, a camera) to the INPUT BNC connector.
  • Page 7: Technical Specifications

    WEIGHT: ACCESSORIES: 1 Specifications are subject to change without notice Technical Specifications of the VM-2HD HD/SD - SDI DA 1 SMPTE-259M, 292M, 344M serial video, 75 ohms on a BNC connector 2 equalized and reclocked SMPTE-259M, 292M, 344M outputs 75 ohms on BNC connectors...
  • Page 8 EXCLUSION OF DAMAGES The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall not be liable for: Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss of time, commercial loss;...
  • Page 9 For the latest information on our products and a list of Kramer distributors, visit our Web site: www.kramerelectronics.com, where updates to this user manual may be found. We welcome your questions, comments and feedback. Safety Warning: Disconnect the unit from the power supply before opening/servicing.
