Figure 1-1. ATmega4809 Xplained Pro Evaluation Kit Overview
CURRENT MEASUREMENT
HEADER
USER LED0
TARGET VOLTAGE
SELECT HEADER
UDFN8
CryptoAuthentication™
DEVICE FOOTPRINT
Info: There is no IC mounted on the UDFN8 CryptoAuthentication footprint.
©
2020 Microchip Technology Inc.
ATmega4809 Xplained Pro
EXTENSION 3 HEADER
User Guide
Introduction
SW0 USER BUTTON
RESET BUTTON
DEBUG USB
POWER HEADER
AVR
®
FOR EXTERNAL
DEBUGGER
EXTENSION 1 HEADER
32.768 kHz Crystal
ATmega4809
mikroBUS™ socket
EXTENSION 2 HEADER
DS50002716C-page 5
DEBUG
