Start-up
mounting plate to the wall (see figure 9).
6. Insert the electronic unit (A) into the wall mounting
plate (see figure 10). Make sure that the electronic
unit properly engages into the wall mounting plate.
5.2.3

Flush-mounted box mounting

You can mount the DHC Room Thermostat on a
flush-mounted box using the screw holes (see figure 11).
If the accessory is mounted to a flush-mounted
box, there may be no open conductor ends.
If changes or works have to be made on the house
installation (e.g. extension, bypass of switch or
socket inserts) or the low-voltage distribution for
mounting or installing the accessory, the following
safety instruction must be considered:
Only to be installed by persons with the relevant
electro-technical knowledge and experience!*
Incorrect installation can put your own life at risk and the
lives of other users of the electrical system. Incorrect instal-
lation also means that you are running the risk of serious
damage to property, e.g. because of a fire. You may be per-
sonally liable in the event of injuries or damage to property.
Contact an electrical installer!
