4. Remove the protective film from the adhesive strips
(see figure 7).
5. Press the assembled DHC Room Thermostat with
the back side to the wall (see figure 7).
5.2.2
Screw mounting
To mount the DHC Room Thermostat with screws, proceed
as follows:
1. Choose a site for installation.
Make sure that no electricity or similar lines run in
the wall at this location!
2. Position the wall mounting plate on the desired site
on the wall. Make sure that the arrows on the back
side of the wall mounting plate point upwards (see
figure 8).
3. Use a pen to mark the positions of the two screw
holes according to the wall mounting plate, with a
distance of 60 mm, on the wall (see figure 8).
4. Drill the marked holes (see figure 9).
If you are working with a stone wall, drill the marked
5 mm holes and insert the plugs supplied. If you are
working with a wooden wall, you can pre-drill
1.5 mm holes to easier insert the screws.
5. Use the supplied screws and plugs to fix the wall
Start-up
21
