Installation and Features

Unpacking

When you receive the unit, immediately unpack it and all accessories and check for possible
damage, obvious or concealed. In case of damage, immediately notify the carrier and take
any steps necessary to file a claim for the damage sustained. Do not destroy the shipping
carton. The carton should be reused if the device must be shipped for any reason. The carton
is specially designed to protect the unit from shipping damage. Improper packaging of the
unit during transport can result in damage and invalidate the warranty.
Complete the warranty registration form and return it to Dynatronics within 10 days of
purchase. This is essential to insure you are not billed for services that are covered by
the warranty policy. Warranty registration should include serial numbers for both the
device and soundheads.
Connect the AC power cord, which is equipped with a hospital grade, UL listed plug, to a
properly grounded 110/120V 60 Hz AC outlet (the device will automatically switch to
220/240V 50 Hz when connected to a power source with that voltage). The power cord must
also be firmly plugged into the device itself. When the cord is properly connected, it can not
be easily pulled out. Do not place the cord or the device in a place where the cord could be
tripped over or accidentally pulled out of its socket during a treatment.
Read the operating instructions in this manual before proceeding with a treatment.

Standard Accessories

The following accessories are included with the Dynatron 850plus or 550plus units:
Qty
1
1
1
1
2
1
1
4
4
2
1
1
1
Dynatron
Part No. Description
D851/ D551 Dynatron
9B0031 Power Cord
8A0061 Patient Remote Stop Cable
8H0006 Operator's manual
7B0230/ 7B0231 72" double leads (1 red, 1 black)
7B0234 Special lead wire for combination treatments (with Dynatron
850plus only)
7B0204 POLYS™ self-adhesive electrodes 1.75" x 3.75" w/pin
connector (pkg of 4)
7B0063/ 7B0065 3" round carbon electrodes (2 red, 2 gray)
7B0191 Sponge fabric for use with carbon electrodes
DW248 2" x 48" straps
7B0191 5" x 8" dispersive electrode for high volt w/ sponge fabric
7B0202 Applications manual
7B0217 Ultrasound gel sample (with Dynatron 850plus only)
850plus & 550plus
®
850plus or Dynatron
®
5
550plus unit
®
