SCAN SETTINGS WINDOW

REGARDING THE SETTING ITEMS OF THE SCAN SETTINGS WINDOW

Job Name list box
This shows the selected job file name. When a job file is not selected, the job file in the default
setting is selected and "Default" appears in the box. When the job file in the default setting is not
specified, ["Untitled "] appears in the box.
Job Load button
This opens the Job Selection dialog box (p.76).
Job Registry button
This opens the Job Registry dialog box (p.86).
This allows you to save (register) the settings in the Scan Settings dialog box naming it as a job
file.
Input Resolution list box
This allows you to specify an input resolution by selecting from the values displayed in this list or
by inputting value directly.
The values displayed in this list vary depending on the film format as shown below.
The value with "#" is the default setting.
<When selecting 35 mm, APS Cassette, APS Sleeve, Transparent Media, 16 mm or Center
area 2820>
2820/1410/940/#705/470/352/282
(When inputting value directly, the desired value from 176 to 2820 is available.)
<When selecting 6 x 4.5, 6 x 6, 6 x 7, 6 x 8, 6 x 9, TEM Film, Whole area interpolation 2820>
2820/1128/564/376/#282/188/141/112
(When inputting value directly, the desired value from 70 to 2820 is available.)
Output Resolution list box
This allows you to specify an output resolution by selecting from the values displayed in this list
or by inputting value directly.
The values displayed in this list are the followings.
The value with "#" is the default setting.
2400/1200/800/720/600/400/360/350/#300/240/200/180/150/96/72/36
(When inputting value directly, the desired value from 36 to 2400 is available.)
• When "pixel" is selected in the Unit list box, the output resolution cannot be selected or
specified.
Input Size text box
This allows you to specify an input size. Although the input size is normally determined according
to the size of the cropping frame you specified (p.42 to 44), you can also input a value in each W
(wide) or H (Height) box. In this case, the size of the cropping frame changes according to the
value you input.
• When "pixel" is selected in the Unit list box, the input resolution cannot be selected or specified.
– 81 –
