Variation Correction - Brightness & Contrast Correction - Minolta DIMAGE SCAN MULTI II F-3100 Instruction Manual

IMAGE CORRECTION
VARIATION CORRECTION – BRIGHTNESS & CONTRAST CORRECTION
Variation Amount Control slider
Limit indication checkbox
In the Brightness & Contrast correction, 8 images that have been corrected from the center
image by one-step in the horizontal direction for brightness and in the vertical direction for
contrast are displayed. When the image in the direction to be corrected is clicked, the image is
placed in the center and new variation images are displayed.
By dragging the Variation Amount Control slider, the value of correction can be changed in the
range from 1 to 20 (The initial value is 10).
When the Limit indication check box is checkmarked and the brightness and contrast are
corrected, any part of the image which has been corrected beyond the range which can be
displayed is displayed in reversed colour.
– 62 –
