Slide Feeder (Optional Accessory) - Minolta DIMAGE SCAN MULTI II F-3100 Instruction Manual

SLIDE FEEDER (optional accessory)

The optional slide feeder can scan automatically up to 50 mounted 35mm slides continuously.
The data of scanned images can be also saved onto a hard disc, etc.
For the names of parts of the slide feeder, and instructions for attaching to or detaching from the
Dimage Scan Multi II or loading the slides, see the instruction manual supplied with the slide
feeder.
1 Attach the slide feeder to the Dimage
Scan Multi II and load the slides by
following the procedure described in
the instruction manual supplied with
the slide feeder.
2 Select Slide Feeder from the Film
Format list box and select the film to
be set from the Film Type list box.
3
Click on
• The first slide to be scanned in the supply-
side storage (on the left side) is loaded into
the scanner and prescanned, and the pres-
can image is displayed.
• The cropping frame function or image correc-
tions described on page 48 to 68 or the
Digital ROC/GEM functions described on
page 69 to 73 can be applied to the prescan
image.
4
After performing the image correc-
tion, click on
dow.
• The file save dialog box will appear.
• The same image correction performed for the
prescan image is applied to the other slides.
– 102 –
in the Main window.
in the Main win-
