INSERTING THE HOLDER INTO THE SCANNER

EJECTING

1. Press the power switch to turn
the scanner on. Turn on your
computer, then launch the
Dimâge Scan Multi software.
• The green indicator lamp will blink
slowly while the scanner is setting up.
2. Insert the holder into the
scanner in the direction
indicated by the white arrow
on top of the holder.
• Do not insert the holder at an angle.
3. Gently push the holder into
the scanner until the raised
insertion mark
with the film-slot door.
• The film holder will be automatically
guided in past the
• If the holder is not loaded correctly,
then eject and reinsert it.
1. Press the eject button on the
front of the scanner.
• The holder will automatically eject
partway, then stop.
2. Remove the holder.
• Wait for the Indicator lamp to turn off
before removing the holder.
• The holder should pull out easily.
23
is aligned
mark.
