- Page 1 DIRIS Digiware 2018 demo case Quick start guide DIRIS Digiware demo case Quick start guide...
-
Page 2: Table Of Contents
Table of Contents Demo case - list of devices ......................3 Demo case general presentation ....................4 System diagram .......................... 5 Powering on the demo case: ....................... 5 WEBVIEW demonstration ......................6 DIRIS Digiware demo case Quick start guide... -
Page 3: Demo Case - List Of Devices
1) Demo case - list of devices Product part no Product description Quantity 48290120 Alimentation 24VDC P15 48290202 DIRIS Digiware D-70 DIRIS Digiware AC 48290102 DIRIS Digiware U-30 48290130 DIRIS Digiware I-35 48290161 DIRIS Digiware S-135 48290140 DIRIS Digiware IO-10 48290145 DIRIS Digiware IO-20 48290101... -
Page 4: Demo Case General Presentation
2) Demo case general presentation Front plate: DIRIS Digiware AC & DC, DIRIS A-40 Inside : AC and DC sensors, Power supplies and router The new demo case enables sales people to present the Digiware system quickly and efficiently. All products are pre connected so that no time is wasted putting the system together during customer visits. -
Page 5: System Diagram
The demo case is not intended to lend devices to customers as the products inside may not be functional to perform real measurements. 3) System diagram The following system is wired inside the Digiware demo case: 4) Powering on the demo case The demo case is powered on by connecting the power cord (included with the demo case) to the power entry module. -
Page 6: Webview Demonstration
5) WEBVIEW demonstration Connecting to the router: On your laptop, select the Digiware demo case from the network list. The password is labelled on the router (Socomec-digiware). DIRIS Digiware demo case Quick start guide... - Page 7 Connecting to WEBVIEW: Once connected to the router, you can connect to WEBVIEW-M on the D-70 or WEBVIEW-S on the DIRIS A-40. For WEBVIEW-M, enter the IP address of the D-70 (192.168.0.4) in your web browser: DIRIS Digiware demo case Quick start guide...
- Page 8 For WEBVIEW-S, enter the IP address of the DIRIS A-40 (192.168.0.5) in your web browser: Visualizing historical measurements, load curves / demand profiles: DIRIS Digiware demo case Quick start guide...
- Page 9 Visualizing consumption curves: Accessing Photoview: DIRIS Digiware demo case Quick start guide...
- Page 10 Alarms and events: DIRIS Digiware demo case Quick start guide...
