superbrightleds HLV5 Series Installation Manual

Important: Read all instructions prior to installation.
LED Headlight Kit
Installation Instructions H16 / PSX24W
Secure driver using included wire ties
Insert the lamp body until clips
and double sided tape.
engage (as shown).
Installation Instructions
H8 / H11 / H13 / P13W / 9004 / 9005 / 9006 / 9007 / 9012 / PSX26W / P13W / 880 / 881
Insert lamp body as shown being
sure to align locking ring tabs.
Secure using included zip ties
and double sided tape.
To adjust beam pattern,
remove allen screw on
locking ring. Rotate bulb
body to desired position.
Reinstall allen. Ensure LEDs
are positioned as in FIG1.
Rev Date: V1 04/14/2017
User Manual
Part Number:
HLV5 Series
Connect bulb to original
connector.
Rotate lamp body until it stops.
Connect bulb to original connector
LED Headlight Kit
Installation Manual
HLV5 Series
Rev Date: V1 04/14/2017
IP 67
WATERPROOF
