superbrightleds PLLD4 Series User Manual

Important: Read all instructions prior to installation.
LED Parking Lot/Area Light
PLLD4-50K300W-BLT3BR1with PLLD4-SF

Specifications

Environmental Specifications
Operating Temperature
IP Rating

Wiring Diagram

120–277 / 277–480 VAC Input
Line
L
Neutral
N
Ground
GND

Mounting Options

Dim (+)
+
Dim (-)
Slip-Fitter (PLLD4-SF)
-
Wall/Trunnion Mount (PLLD4-WM)
-31°–122° F (-35°–50° C)
IP65
Black
L
White
N
Green
GND
Purple
+
Gray / Pink
Adjustable Pole Mount (PLLD4-APM)
-
Flood Mount (PLLD4-FB1, PLLD4-FB2)

Safety and Notes

• Product should be installed and serviced by a certified electrician
in accordance with applicable national, state, and local building
and electrical codes.
• To reduce the risk of electric shock, ensure that the main power
source and circuit breakers are switched off before performing
any installation or wiring procedures.
• Avoid looking directly into lamp when illuminated.
• Ensure all mounts are securely attached and will support the
weight of the fixture. Failure to properly support fixture may
result in damage or injury, for which the manufacturer does not
assume responsibility.
Check product label for specific electrical
specifications related to installation.
Line
Improper installation will void warranty.
L L
Neutral
N N
Ground
GND GND
1–10 V / 0–10 V Dimming
Dim (+)
+ +
Dim (-)
- -
