versions ONLY!
The reference level is now programmed into the system.
The lift is now back into normal mode.
Direct the lift to the desired landing.
The display shows:
alternatively . . .
Calibration drive from landing or B-panel when car is located
at bottom landing:
– Press Call button and the lift will accelerate upward until it
has left the reference cam, then it decelerates and stops.
– The lift will automatically move down in slow speed and just
before it reaches the reference cam it will reduce the speed to
crawling speed. The lift continues in crawling speed down to
the bottom landing.
The reference level is now programmed into the system.
The system is now back into normal mode.
Direct the lift to the desired landing.
Calibration drive from landing or B-panel when car is located
somewhere above the bottom landing:
– Press Call button and the lift will move downwards until it
reaches the reference cam, then it decelerates and stops.
– The lift will automatically accelerate upwards until it has
left the reference cam, then it decelerate and stops.
– The lift will once again automatically start and move down
in slow speed and just before it reaches the reference cam it
will reduce the speed to crawling speed. The lift continues in
crawling speed down to the bottom landing.
The reference level is now programmed into the system.
The system is now back into normal mode.
Direct the lift to the desired landing.
0 lights up on the display
for the single system.
. . . or with
joystick . . .
ALIMAK 335053 - 1/09
. . . or ''0'' for
permanent lifts
