versions ONLY!
Landings are NOT stored into system
Calibration drive from inside of the car when lift is located at
bottom landing:
The display shows:
(no landings are programmed into the system):
– Press Up button and the lift will accelerate upwards until it
has left the reference cam, then it decelerates and stops.
– The lift will automatically move down in slow speed and
just before it reaches the reference cam it will reduce the
speed to crawling speed. The lift continues in crawling
speed down until it reaches the reference cam and then the
lift will stop.
The display shows:
The reference level is now programmed into the system.
The lift is now back into normal mode but no landings are
programmed into the system.
See page Programming of landings.
Calibration drive from inside of the car when lift is located
somewhere above the bottom landing:
The display shows:
(no landings are programmed into the system):
– Press Down button and the lift will move downwards until it
reaches the reference cam, then it decelerates and stops.
– The lift will automatically accelerate upwards until it has
left the reference cam, then it decelerates and stops.
– The lift will once again automatically start and move down
in slow speed and just before it reaches the reference cam it
will reduce the speed to crawling speed. The lift continues in
crawling speed down until it reaches the reference cam and
then the lift will stop.
The display shows:
The reference level is now programmed into the system.
The system is now back into normal mode, but no landings
are programmed into the system.
See page Programming of landings.
CD flashes on the display
for the single system.
CD flashes on the display
for the single system.
ALIMAK 335051 - 1/09
alternatively . . .
. . . or with joystick . . .
. . . or ''0'' for
permanent lifts
