Alimak ALC II User Manual page 28

A
22
alternatively . . .
. . . or with joystick . . .
. . . or ''0'' for
permanent lifts
Landings ARE stored into the system
Calibration drive from inside of the car when lift is located at
bottom landing:
The displays show:
(if 5 landings are programmed into the system).
– Press Up button and the lift will move upwards until it has
left the reference cam and then it stops.
– The lift now automatically moves down to the bottom and
stops.
The reference level is now programmed into the system.
The system is now back into normal mode.
Direct the lift to the desired landing.
The display shows:
Calibration drive from inside of the car when lift is located
somewhere above the bottom landing:
The displays show:
(if the number of programmed landings is 5).
ALIMAK 34829 - 1 /04
CD and 5 flash alternately
on the display for the
single system.
0 lights up on the display
for the single system.
CD and 5 flash alternately
on the display for the
single system.
