Assembly Instructions & User's Manual
for
Member's Mark Athena 7 Piece Dining Set
980297041
Item Number:
FW-ANS7DND
Model Number:
Customer Assistance
: 1-800-443-1410
(spare/replacement parts)
customerservice@foremostgroups.com
or Email:
DISCLAIMER: Supplier is fully responsible for the entire content of the assembly manual, in-
cluding all Sam's Club suggested edits or revisions.
THIS ASSEMBLY MANUAL CONTAINS INPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Member's Mark FW-ANS7DND
Summary of Contents for Member's Mark FW-ANS7DND
- Page 1 Assembly Instructions & User’s Manual Member’s Mark Athena 7 Piece Dining Set 980297041 Item Number: FW-ANS7DND Model Number: Customer Assistance : 1-800-443-1410 (spare/replacement parts) customerservice@foremostgroups.com or Email: DISCLAIMER: Supplier is fully responsible for the entire content of the assembly manual, in- cluding all Sam’s Club suggested edits or revisions.
-
Page 2: Table Of Contents
Table of Contents Quality Statement ..........................3 Important Safety Information......................3 Before Assembly..........................3 Care & Use ............................3 Package Contents ..........................4 Product Information ........................... 5 Components ............................5 Hardware .............................. 6 Tools..............................6 Step 1 ..............................7 Step 2 ..............................8 Step 3 .............................. -
Page 3: Quality Statement
Quality Statement Important Safety Information • Please read all instructions carefully before assembling this furniture. • For your safety, assembly by two or more adults is strongly recommended. • Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item. •... -
Page 4: Package Contents
Package Contents Component Description Quantity Component Description Quantity Umbrella Hole Lid Chair Frame Chair leg Furniture Cover Seat Cushion Table Top Table Leg Need Assistance? Visit us at: samsclub.com/membersmarkhelp... -
Page 5: Product Information
Product Information Dimension: Dining Chair: 27.50” x 25.00” x 36.25” Dining Table: 80.00 “x 40.00” x 29.50” Weight Capacity: Dining Chair: 250 lbs Components Component A Component B Component C Part No. PF-ANS-DC-A-20 Part No. PF-ANS-DC-B-20 Part No. PF-ANS-DC-C-20 Qty 6 Qty 24 Qty 6 Component D... -
Page 6: Hardware
Hardware Bolt (M6 x 25 mm) AA Bolt (M8 x 40 mm) BB Washer (M6) CC Part No. PF-ANS-DC-HP-20 Part No. PF-ANS-DT-HP-20 Part No. PF-ANS-DC-HP-20 Qty 72 Qty 8 Qty 72 Washer (M8) DD Lock Washer (M6) EE Lock Washer (M8) FF Part No. -
Page 7: Step 1
STEP 1 Place the Chair Seat (A) at its side on a soft, smooth surface. Loosely attach the Chair Legs (B) to the Chair Seat (A) using M6 x 25 mm Bolts (AA), Lock Washers (CC) and Washers (DD). Once all Bolts (AA) are in place and the Chair Legs (B) are aligned with the Chair Seat (A), tighten all Bolts (AA) with supplied Allen Wrench (EE). -
Page 8: Step 2
STEP 3 Turn the chair to the upright position and place the Seat Cushion (C) on the chair and check the stability. If the chair wobbles, loosen the foot glider counter clockwise until the chair stands completely stable. Then your chair is ready for your enjoyment. Need Assistance? Visit us at: samsclub.com/membersmarkhelp... -
Page 9: Step 3
STEP 3 Place the Table Top (D) upside down on a soft, smooth surface. Position the Table Legs (E) into the corner sockets on the Table Top (D). Loosely secure with M8 x 40 mm Bolts (BB), M8 Lock Washers (FF) and M8 Flat Washers (HH). -
Page 10: Step 4 - Step 5
STEP 4 Turn the table to the upright position and check the stability. If the table wobbles, loosen the foot glider counter clockwise until the table stands completely stable. Please cover the umbrella hole with the umbrella hole lid (G) if you don’t need the umbrella at the moment. The dining table is ready for your enjoyment. - Page 11 STEP 6 Elastic hem with cord lock Buckle Strap Wrap the buckle straps around the furniture legs and tighten the elastic hem to secure the cover in place. Need Assistance? Visit us at: samsclub.com/membersmarkhelp...
-
Page 12: Warranty Information
Warranty Information Limited Manufacture’s 5 Years Warranty General Residential Warranty We warranty all our residential use furniture 5 years. The warranty is valid from the date you purchase and applies only to the original purchaser. If your frame fails structurally during normal usage (other than damage as a result of dropping or breaking a cast part other than a weld is not covered under this warranty) or if the finish peels, cracks or blis- ters within 1 year, we will repair , refinish or replace the frame at manufacturer’s discre-... - Page 13 Warranty Information Table Tops (if applicable ) All stone tops are warranted for a period for one (1) from original date of purchase, against defects in material and or workmanship. Breakage, discoloration, staining, and or any other weather-related issues are not covered. Firepits Bumer, cast aluminum &...
- Page 14 Distributed by Sam’s West Inc. 2101 SE Simple Savings Dr. Bentonville, Arkansas 72716-0745 Made in Indonesia Need Assistance? Visit us at: samsclub.com/membersmarkhelp...
