Assembly Instructions & User's Manual
for
Member's Mark Kimberly 5pc Deep Seating
Set
Item Number:
Model Number: FRS10387SAST
Customer Assistance
: 1-888-690-9800
(spare/replacement parts)
or Email: cs@sunvillahome.com
THIS ASSEMBLY MANUAL CONTAINS INPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1 |
P a g e
Advertisement
Table of Contents
Related Manuals for Member's Mark Kimberly FRS10387SAST
Summary of Contents for Member's Mark Kimberly FRS10387SAST
- Page 1 Assembly Instructions & User’s Manual Member’s Mark Kimberly 5pc Deep Seating Item Number: Model Number: FRS10387SAST Customer Assistance : 1-888-690-9800 (spare/replacement parts) or Email: cs@sunvillahome.com THIS ASSEMBLY MANUAL CONTAINS INPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. P a g e...
-
Page 2: Table Of Contents
Table of Contents Quality Statement ............................. 3 Important Safety Information ........................ 3 Before Assembly ............................3 Care & Use ..............................3 Package Contents ............................ 4 Product Information ..........................5 Components .............................. 5 Hardware ..............................5 Tools ................................6 Step 1 – Step 8 ............................6 Troubleshooting ............................ -
Page 3: Quality Statement
Quality Statement Important Safety Information • Please read all instructions carefully before assembling this product. • Where applicable, and for your safety, assembly by an adult is strongly recommended. • Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item. -
Page 4: Package Contents
Package Contents Component Description Quanti Component Description Quantity Coffee Table-Large Sofa Frame Coffee Table-Small Sofa Back Chair Frame Furniture Cover for Coffee Table Chair & Sofa Seat Furniture Cover for Cushion Chair Chair & Sofa Back Furniture Cover for Cushion Sofa Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e... -
Page 5: Product Information
Product Information Dimensions: Coffee Table-Large: φ33.07”x18.5” (φ84cm x 47cm) Coffee Table-Small:φ25”x15.94” (φ63.5cm x 40.5cm) Chair: 32.28”x35.82”x39.56” (82cm x 91cm x 100.5cm) Sofa: 80.31”x35.82”x39.56” (204cm x 91cm x 100.5cm) Weight Capacity: Chair: Supports up to 250 lbs. (113.4kg.) Sofa: 250lbs (113.4kg.) per each seat Components Chair Frame Chair &... -
Page 6: Tools
Tools Wrench (Included) Step 1 – Step 8 Step 1 Lift up the chair back to the upright position. To secure chair frame, snap bolt onto latch to lock in place. Step 2 Place cushion shown as below before use. Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e... - Page 7 Step 3 Step 4 Step 5 Lift up the sofa back to the upright position. To secure sofa frame, snap bolt onto latch to lock in place Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e...
- Page 8 Step 6 Place cushion shown as below before use. Step 7 If necessary, you can adjust the feet to level the sofa. Step 8 When furniture is not in use, put covers on them to prevent dust. Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e...
-
Page 9: Troubleshooting
Troubleshooting Problem Possible Cause Prevention / Solution Table is unstable Hardware may loosen overtime. Periodically check that all connections are tight. Storage Instructions 1. Carefully place all components into shipping box and/or provided container tape it shut. 2. When not in use, please store your item in a cool, dry place away from sunlight. 3. -
Page 10: Warranty Information
Warranty Information This product component has a 3 years guarantee against defects in material and/or workmanship. If you have any questions regarding the warranty or spare / replacement parts, please call our toll-free number 1-888-690-9800 or email us at cs@sunvillahome.com NOTE: Please consider recycling all applicable packaging material.
