Assembly Instructions & User's Manual
for
Member's Mark Kennan 4pc Deep Seating
Set
Item Number: TBD
Model Number: FZA10218ST
Customer Assistance
: 1-888-690-9800
(spare/replacement parts)
or Email: cs@sunvillahome.com
THIS ASSEMBLY MANUAL CONTAINS INPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1 |
P a g e
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Member's Mark Kennan TBD FZA10218ST
Summary of Contents for Member's Mark Kennan TBD FZA10218ST
- Page 1 Assembly Instructions & User’s Manual Member’s Mark Kennan 4pc Deep Seating Item Number: TBD Model Number: FZA10218ST Customer Assistance : 1-888-690-9800 (spare/replacement parts) or Email: cs@sunvillahome.com THIS ASSEMBLY MANUAL CONTAINS INPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. P a g e...
-
Page 2: Table Of Contents
Table of Contents Quality Statement ............................. 3 Important Safety Information ........................ 3 Before Assembly ............................3 Care & Use ..............................3 Package Contents ............................ 4 Product Information ..........................5 Components .............................. 5 Hardware ..............................6 Tools ................................6 Step 1 – Step 11 ............................6 Troubleshooting ............................ -
Page 3: Quality Statement
Quality Statement Important Safety Information • Please read all instructions carefully before assembling this product. • Where applicable, and for your safety, assembly by an adult is strongly recommended. • Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item. -
Page 4: Package Contents
Package Contents Component Description Quantity Component Description Quantity Chair Frame Cast Cap Chair Base Inner Cap 1 Chair Seat Cushion Inner Cap 2 Chair Back Cushion Inner Cap 3 Table Top Chair Frame Table Leg Furniture Cover Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e... -
Page 5: Product Information
Product Information Dimensions: Swivel chair: 28.9''Dx22.6''Wx36''H (73.5cm x 57.5cm x 91.5cm) Stationary chair: 28.9''Dx22.6''Wx36''H (73.5cm x57.5cm x 91.5cm) Table: table: 79.9''Dx40.1''Wx30.1H (203cm x 102cm x 76.5cm) Weight Capacity: Chair: Supports up to 250 lbs. (113.4kg.) Sofa: 250lbs (113.4kg.) per each seat Components Chair Frame Chair Base... -
Page 6: Hardware
Hardware M8x45 Bot/Φ16x1.6 Φ8xΦ13x2.0 Spring Washer/ Washer Plate Qty:8 (4 per chair) Qty:8 (4 per chair) Qty:8 (4 per chair) Nut M8 M8x45 Bolt Qty:8 (4 per chair) Qty:8 Tools Wrench (Included) Step 1 – Step 11 Step 1 Step 2 Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e... - Page 7 Step 3 Step 4 Step 5 Step 6 Step 7 Step 8 Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e...
- Page 8 Step 9 Step 10 Step 11 When furniture is not in use, put covers on them to prevent dust. Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e...
-
Page 9: Troubleshooting
Troubleshooting Problem Possible Cause Prevention / Solution Chair/Table is Hardware may loosen overtime. Periodically check that all connections are tight. unstable Storage Instructions 1. Carefully place all components into shipping box and/or provided container tape it shut. 2. When not in use, please store your item in a cool, dry place away from sunlight. 3. -
Page 10: Warranty Information
Warranty Information This product component has a 3 years guarantee against defects in material and/or workmanship. If you have any questions regarding the warranty or spare / replacement parts, please call our toll-free number 1-888-690-9800 or email us at cs@sunvillahome.com NOTE: Please consider recycling all applicable packaging material.
