Summary of Contents for First Degree Fitness FLUID E750
- Page 1 USER GUIDE E750 FLUID EXERCISE...
- Page 3 Training with the E750 Congratulations on your purchase of E750. FIRST DEGREE FITNESS is proud to present the Unit as a full commercial use product featuring patented Adjustable Fluid Resistance. As with any piece of fitness equipment, consult a physician before beginning your E750 exercise program.
-
Page 4: Table Of Contents
Contents Safety ................... 5 Assembly ................7 Box Contents ................8 Assembly Instructions ............. 9 Operation Instructions ..............12 Bluetooth Auto-Adjust Monitor ..........15 Calibration Procedure ............16 Maintenance & Troubleshooting ........... 17 Tank Belt Adjustment ..............19 International Warranty ............20... -
Page 5: Safety
Safety Safety Information • Before using this product, it is essential to read this ENTIRE operation manual and ALL instructions. The Unit is intended for use solely in the manner described in this manual. • UNDERSTANDING EACH AND EVERY WARNING TO THE FULLEST IS IMPORTANT •... - Page 6 Inspection • DO NOT use or permit use of any equipment that is damaged and/or has worn or broken parts. For all FIRST DEGREE FITNESS equipment use only replacement parts supplied by FIRST DEGREE FITNESS. • EQUIPMENT MAINTENANCE - Preventative maintenance is the key to smooth operating equipment as well as to keep your liability to a minimum.
-
Page 7: Assembly
Assembly Product Specifications Product Class: SC Braking System: Speed Independent Product Net Weight: 101.4kg (223.5lb) Product Gross Weight: 120.8kg (266.3lb) Maximum Safe Operating Surface Area: 253cm (99.61”) Length x 217cm (85.43”) Width Dimensions: 1330mm (52.36”) Length x 970mm (38.19”) Width x 1520mm (59.84”) Height Maximum User Weight: 150kg (330lb) Footprint:1930mm x 1570mm... -
Page 8: Box Contents
Box Contents Item Qty. Description Item Qty. Description Main Frame Right Crank Pedal Lower Seat Frame Seat Frame lubricating grease Upper Seat Frame Multi-Tool Seat Back D Cell Battery Lower Seat Touch Up Paint L-pin Funnel and Hose Leveler Owners Manual Hardware Kit M6x20mm Bolt M10 Nylock Nut... -
Page 9: Assembly Instructions
Assembly Instructions STEP 1 Assembly Seat Back and Lower Seat REQUIRED Seat Back[4] to Upper Seat Frame[3] using Upper Seat Frame [3] 4x M6x20mm Bolts[15] and 4x M6 Washers[17] Seat Back [4] b) Lower Seat[5] to Upper Seat Frame[3] using 4x M6x20mm Bolts[15] and 4x M6 Washers[17] Lower Seat [5] 8 x M6 x 20mm Blots [15]... - Page 10 Assembly Instructions STEP 3 Assembly Upper Seat Frame and Lower Seat Frame REQUIRED Upper Seat Frame[3] onto Main Frame[1] and secure using 1x Main Frame [1] M10x25mm Bolt[16],1x M10 Nyloc Nut[20], 2xM10 Washers Upper Seat Frame [3] [18], M10 Plastic Washer[19] and L-pin[6]. L–...
- Page 11 Assembly Instructions STEP 5 Support Kit Assembly REQUIRED Let the machine lie down carefully. M8x55 Bolt[24] Assemble the Support Plate[28] using M8x55 Bolt[24] M8x90 Bolt[25] 2 x M8 Washer[26] and M8 Washer[26] and M8 Nyloc Nut[27]. 2 x M8 Nyloc Nut[27] Support Plate[28] Stand the machine.
-
Page 12: Operation Instructions
Operation Instructions E750 Control Arm Chain Tensioning Bolts: Allows for tightening the chain or adjustment from side to side. Make sure when tightening only to adjust the same amount for both Bolts, otherwise the sprocket will be misaligned. Note: Tightening the right Bolt only will pull the right side of the crank assembly toward you, tightening the left will pull the left side toward you. - Page 13 (rechargeable via USB) available as an option. We recommend this to any commercial facility, with multiple units, that has a need to drain and refill Tanks from time to time. To purchase, contact your nearest First Degree Fitness distributor or go to our website on www.firstdegreefitness.com for details.
- Page 14 Operation Instructions CHANGING RESISTANCE LEVEL Changing resistance on your Unit is simple. The level of resistance is determined by the level indicator located on the front of the Tank. Level one indicates lightest resistance, level ten represents heaviest resistance. The Tank‟s variable fluid resistance technology ensures an instant catch and constant resistance throughout the movement.
-
Page 15: Bluetooth Auto-Adjust Monitor
Bluetooth Auto-Adjust Monitor Auto Start: Commence exercise to activate. Reset all values: Press and hold RESET button for 3 seconds. Auto Power Down: Over 5 minutes. All values revert to zero after restart. WATT: Power measured in watts WORK: Duration of exercise segment REST: Duration of rest period POWER GRAPH: Press RESET to change display from Power Curve to Cumulative Power Graph. -
Page 16: Calibration Procedure
Calibration Procedure Press and hold 「RESET」and「REST」for 5 seconds. Display will show “ Level 1“ Turn handle to Level 1. Press Reset. Display will now show Level 2. Level 1 Calibration is complete. Turn handle to Level 2. Press Reset. Display will now show Level 3. Level 2 Calibration is complete. -
Page 17: Maintenance & Troubleshooting
Tanks from time to time. To purchase, contact your nearest First Degree Fitness distributor or go to our website on www.firstdegreefitness.com for details. The Monitor display is erratic and illuminates, It is possible that there is a loose connection. - Page 18 Maintenance & Troubleshooting Item Time Frame Instructions Wipe down weekly with lint free cloth or more often with Seat and Frame. Weekly. heavy club use. Check monthly for signs of slippage. Adjust/tighten as PK Belt Tension. Monthly. required. Tank and Water Follow instructions as specified in the “Water Treatment”...
-
Page 19: Tank Belt Adjustment
Tank Belt Adjustment 2. Using a long tool, push out the rear 1. Remove large metal inspection plate. end cap as pictured below left. This will give you access to the Tank tensioning Bolt (shown lower right). End Cap 4. Using a 6mm Allen Key, tighten the 3. -
Page 20: International Warranty
Metal Frame – 10 Year Limited Warranty First Degree Fitness will repair or replace the metal Main Frame should it fail due to any defect in materials or workmanship within 10 years of the original purchase. Warranty does not apply to frame coating. - Page 24 NOUS CONTACTER Pour le soutien à la clientèle, veuillez visiter firstdegreefitness.com/support TAÏWAN T: +886 3 478 3306 764 Chung Shan South Rd Yangmei Taoyuan Taiwan R.O.C.
