ISE smart connect Modbus Vaillant Product Manual page 18

Addr. Name
21 Pressure compressor low
sensor state
22-23 Pressure compressor low
sensor value
24 Compressor outlet
temperature sensor state
25 Compressor outlet
temperature sensor value
26 External top cylinder
temperature sensor state
27 External top cylinder
temperature sensor value
28 External bottom cylinder
temperature sensor state
29 External bottom cylinder
temperature sensor value
30 Error history 1
31 Error history 2
32 Error history 3
33 Error history 4
34 Error history 5
35 Error history 6
36 Error history 7
37 Error history 8
38 Error history 9
39 Error history 10
40 Status heat pump
41-42 Earned environment
energy
43 Outside temperature
sensor state
44 Outside temperature
sensor value
45 Flow temperature
sensor state
46 Flow temperature
sensor value
47 Return temperature
sensor state
48 Return temperature
sensor value
49 Heating circuit pressure
sensor state
50-51 Heating circuit pressure
sensor value
52 Energy integral value
53 VF2 flow temperature
sensor state
54 VF2 flow temperature
sensor value
Order No. S-0002-007
Datatype
sensorState
IEEE 754 single float 2
sensorState
int16_t
sensorState
int16_t
sensorState
int16_t
DTC_EHP
DTC_EHP
DTC_EHP
DTC_EHP
DTC_EHP
DTC_EHP
DTC_EHP
DTC_EHP
DTC_EHP
DTC_EHP
statusMessageEHP
uint32_t
sensorState
int16_t
sensorState
int16_t
sensorState
int16_t
sensorState
IEEE 754 single float 2
int16_t
sensorState
int16_t
ise smart connect Modbus Vaillant
Polling Range
interval
[min]
2
0 – 65.5
2
-2048 –
2
2048
2
-2048 –
2
2048
2
-2048 –
2
2048
15
15
15
15
15
15
15
15
15
15
2
60
15
-2048 –
15
2048
2
-2048 –
2
2048
2
-2048 –
2
2048
2
0 – 65.5
2
2
-2048 –
2
2048
Product Manual Page 18 (45)
Modbus TCP/IP
Reso- Unit
lution
0.1 bar
°C
°C
°C
kWh
°C
°C
°C
0.1 bar
°min
°C
