Product Manual
ISE SMART CONNECT KNX SONOS
1-0001-002
Documentation valid for:
Product database entry:
Firmware:
Documentation status
© 2018 ise Individuelle Software und Elektronik GmbH
v3.0
V3.0
30/10/2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smart Connect KNX Sonos and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ISE Smart Connect KNX Sonos

Summary of Contents for ISE Smart Connect KNX Sonos

  • Page 1 Product Manual ISE SMART CONNECT KNX SONOS 1-0001-002 Documentation valid for: Product database entry: v3.0 Firmware: V3.0 Documentation status 30/10/2018 © 2018 ise Individuelle Software und Elektronik GmbH...

  • Page 2: Legal Information

    Products to which reference is made in this document can be either brands or registered trademarks of the respective rights holder. ise Individuelle Software und Elektronik GmbH and the author make no claim to these brands. The brands are named solely for the purpose of providing the necessary description.

  • Page 3: Table Of Contents

    Table of contents About this documentation ..........................7 Target group ............................7 Symbols and other typographical conventions ..................7 About ISE SMART CONNECT KNX SONOS ..................... 8 Proper use ..............................8 2.1.1 Compatibility with Sonos and ETS ..................... 9 System ..............................9 Functions ...............................
  • Page 4 Communication objects ..........................76 11.1 Connecting group addresses to group objects ..................76 11.2 KNX group objects for dynamic group creation ................... 91 ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 4 / 120...
  • Page 5 16.1 Definitions ............................115 16.2 Object of the agreement ........................115 16.3 Rights of use of the ISE SMART CONNECT KNX SONOS software ..........115 16.4 Restriction of rights of use ........................115 16.4.1 Copying, modification and transmission .................. 115 16.4.2...
  • Page 6 Termination ............................. 118 16.11 Subsidiary agreements and changes to the agreement ............... 118 16.12 Exception ............................118 Open Source Software ..........................119 ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 6 / 120...

  • Page 7: About This Documentation

    About this documentation 1 About this documentation This documentation will accompany you through all phases of the product life cycle of ISE SMART CONNECT KNX SONOS. You will learn for example how to assemble, install, commission and configure the device.

  • Page 8: About Ise Smart Connect Knx Sonos

    Sonos zones. The ISE SMART CONNECT KNX SONOS opens up the world of KNX to the family of sound, making it even eas- ier to handle. At last, Sonos can be operated with KNX operating devices, either in party mode or by room. Up to ten Sonos master devices can be connected via IP with dynamic group creation.

  • Page 9: Compatibility With Sonos And Ets

    ETS online catalogue. 2.2 System ISE SMART CONNECT KNX SONOS is connected to the KNX installation via KNX/TP. The device uses the IP to integrate into the network where the Sonos devices (2) are already located.

  • Page 10: Functions

    Increase/lower volume: To absolute or relative value. Information about the current playback  Title, artist and album in scrolling text on KNX text objects. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 10 / 120...

  • Page 11: Functional Enhancements From Updates

    IP connection. 2.3.1 Functional enhancements from updates Functional enhancements for ISE SMART CONNECT KNX SONOS are available via a newer version of the firm- ware. Simply download the latest firmware and the relevant product manual from our web site www.ise.de.
  • Page 12 Party at the push of button With dynamic group creation, the ISE SMART CONNECT KNX SONOS can switch to party mode triggered by a signal from the building bus. Pressing the "Party" button links all the Sonos devices together, and the house becomes a continuous party zone with the same music playing in all the rooms.
  • Page 13 Not so with the ISE SMART CONNECT KNX SONOS. Activating the "Dinner bell" button function in the kitchen lowers the media volume in the entire house and brings everyone's attention to family mealtime in a peaceful, stress-free way using an unobtrusive audible signal or recorded announcement heard in every room.
  • Page 14 "The cooker is still on!" and "A skylight is still open" can help prevent undesirable things happening. 2.3.3.6 Energy efficiency The Sonos system and ISE SMART CONNECT KNX SONOS help you to use energy more efficiently without los- ing any comfort. A few examples: Don't waste heating energy: "Window opened" announcement If the outside temperature and the position of the windows are known to the KNX system, occupants can be reminded of energy consumption after a period of time and at regular intervals.

  • Page 15: Application Scenarios - Comfort Solutions In The Living Environment

    (as configured). If the door is opened, the rooms become an acoustic unit: The ISE SMART CONNECT KNX SONOS creates a group in which a Sonos device in the living area functions as the master for Sonos devices in the dining room, thus determining music playback.
  • Page 16 The signal is a Sonos playlist, which has been configured as an announcement in a playlist entry. The file with the sound may be on the microSD card in your ISE SMART CONNECT KNX SONOS or on another release. Create the Sonos playlist with the official Sonos soft- ware.

  • Page 17: Commercial Application Scenarios

    About ISE SMART CONNECT KNX SONOS 2.3.5 Commercial application scenarios 2.3.5.1 Announcements in sales and event rooms The ISE SMART CONNECT KNX SONOS can present announcements at the push of a button or at set times. IP data network "Valued custom-...
  • Page 18 Sonos commands (IP). brary on the network, ple: Weather sensor re- from the microSD card ports blue skies. in the device, for exam- ple. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 18 / 120...

  • Page 19: General Safety Instructions

    Store the device in its original packing. The original packing provides optimum protection during transport. Store the device in a temperature range of -25 °C to +70 °C. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 19 / 120...

  • Page 20: Basic Information

    You can connect the Sonos devices in such a way that the music from all Sonos devices within a room is syn- chronised when it plays. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 20 / 120...
  • Page 21 Master-slave groups (MSG)  A master-slave group is a logic grouping of up to six Sonos devices in the ISE SMART CONNECT KNX SONOS. A master-slave group comprises a single master and up to five slaves. ...

  • Page 22: Stereo Pair: Connect Sonos Devices Permanently

    Living room Sonos device Music Figure 4: Two Sonos devices per room which play the same music (grouped as a stereo pair) ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 22 / 120...

  • Page 23: Case Example: Handling Stereo Pairs In The Ets

    Create stereo pairs. Enable configuration for master-slave groups. Configure master in the two master-slave groups. Generate KNX group address and link to ISE SMART CONNECT KNX SONOS's corresponding communica- tion objects. Link KNX group addresses with KNX buttons, visualisations and similar.
  • Page 24 Sonos software in the Sonos docu- mentation. The Sonos software and the ISE SMART CONNECT KNX SONOS regard a stereo pair as a single (1) "visible" Sonos de- vice. You only need to enter the stereo pair's IP address within the ETS.

  • Page 25: Master And Slaves

    Master-slave group 2: Stereo pair 3 as master <<Group 2 master>> 192.168.0.15 Generate KNX group ad- Generate the KNX group addresses and link the ISE SMART CONNECT dress and link to ISE KNX SONOS's corresponding communication objects for the master-slave SMART CONNECT KNX groups 1 and 2;...
  • Page 26 Sonos group. It then takes on the role of a master, which does not necessarily need to be configured as one of the ISE SMART CONNECT KNX SONOS's masters. A stereo pair can also adopt the role of slave.
  • Page 27   <<Repeat all>> With value <<0>>: The com- Is ignored. mand is ignored.  With value 1: <<PlayerIsSlave>> error is sent. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 27 / 120...

  • Page 28: Master-Slave Groups

    Basic information 3.4 Master-slave groups A master-slave group is the logic grouping of six Sonos devices in the ISE SMART CONNECT KNX SONOS. Master-slave groups bring Sonos devices together, so that music can be played in all the master-slave group's rooms in synchronisation.
  • Page 29 "Dinner bell" announcement, so that no-one in the house misses a hot meal. What is the largest possible Sonos group that you can create with the ISE SMART CONNECT KNX SONOS? A Sonos device can be configured as a master in several master-slave groups.

  • Page 30: Both A Master And Slave In The Configuration

    Sonos devices 1, 2 and 4 play Sonos device 1's music in synchronisation. The Sonos devices 2 and 4 lose their master functions which they have in master-slave groups 2, 3 and 4. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 30 / 120...
  • Page 31  You can remove the Sonos device from the Sonos group in the Sonos software. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 31 / 120...
  • Page 32 A Sonos device in a master role does not take its slaves with it to a group where it becomes a slave. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 32 / 120...

  • Page 33: Running Time Error In Alternating Master-Slave Relationships

     Sonos device 1 is a master and plays its music.  Sonos device 2 is a master and plays its music. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 33 / 120...

  • Page 34: Enable Master-Slave Groups In The Ets

    Moreover, the music would then usually not be synchronised, which would be very unpleasant for the party guests. This is where dynamic group creation comes in. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 34 / 120...
  • Page 35 It should still be possible for different music to be played in the two rooms. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 35 / 120...
  • Page 36 Switch group association>>. Result: Sonos device 3 loses its status as a master and becomes the slave. Sonos device 3 now plays music ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 36 / 120...
  • Page 37 Create more groups in the Sonos software You can use your Sonos app to combine any number of rooms into a group or, alternatively, cre- ate a stereo pair. Groups not shown on the ISE SMART CONNECT KNX SONOS are thus also pos- sible.

  • Page 38: Technical Data

    Approvals and protection type Approvals / certifications: CE, KNX Protection type: IP20 (compliant with EN 60529) Protection class: III (compliant with IEC 61140) ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 38 / 120...

  • Page 39: Device Design

    Sonos components. microSD-cards up to 32 GB (SDHC) microSD cards must be formatted in FAT32. (not included in the scope of supply) ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 39 / 120...

  • Page 40: Data On Device Sticker (Front)

     LED lights up yellow-orange: Connected but currently no telegram traffic  LED flashes yellow-orange: Telegram traffic IP: 2x RJ45 (integrated switch) ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 40 / 120...

  • Page 41: Top

    RJ45 cable (not included in the scope of supply) connected to RJ45 socket Figure 11: Side of device, including cover cap and connected RJ45 cable ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 41 / 120...

  • Page 42: Device Website

    Device website 6 Device website You can access ISE SMART CONNECT KNX SONOS via the “Device website” application”. The device website offers the following functions (extract):  ► Configure playlists, p. 62.  ► Check device status, p. 106. The master-slave groups' current status is also displayed on the <<Device status>> page.

  • Page 43: Getting To Know The Interface Of The Device Website

    ► Reset to factory settings, p. 57  ► Generate log files, p. 107  ► Update firmware, p. 59  Restart device ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 43 / 120...

  • Page 44: Installation

    These stickers are also affixed to the device. PACKAGING AND BOX Dispose of the packaging material appropriately, in a card, paper or plastic recycling bins. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 44 / 120...

  • Page 45: Checking The Installation Conditions

     Pay attention to the ambient temperature of the installation environment: Min. 0 °C, max. +45 °C.  Do not mount the ISE SMART CONNECT KNX SONOS above heat-emitting devices.  Ensure that there is sufficient ventilation / cooling. ...

  • Page 46: Mounting The Device

    Installation 7.3 Mounting the device ISE SMART CONNECT KNX SONOS may only be assembled and installed by qualified electricians. Specialist knowledge of the installation regulations is a prerequisite. WARNING Danger from incorrect use Incorrect use can result in damage to the device, fire or other dangers.
  • Page 47 The operating currents of all KNX/TP devices on the line section must not exceed the rated cur-  rent of the power supply. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 47 / 120...
  • Page 48 The network connections are located on the underside of the device. Connect the IP network cable (RJ45 cable) to the device's network connection (RJ45 pin jack). ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 48 / 120...

  • Page 49: Commissioning And Configuration

    ► Table 11: "COM" LED in operation, p. 52 The "Programming" LED shows independently of the operating mode whether the device is in programming mode or not. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 49 / 120...
  • Page 50  LED lights up yellow-orange: Connected but currently no telegram traffic  LED flashes yellow-orange: Telegram traffic IP: 2x RJ45 (integrated switch) ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 50 / 120...

  • Page 51: Leds When The Device Starts Up

    (invalid firmware). (off)…..(green)…..(off)…..(green)…..  Please contact support. (yellow)…..(off)…..(yellow)…..(off)….. ► Contacting Support, p. 108 Slow flashing (about 1 Hz) in an alternating pattern ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 51 / 120...

  • Page 52: Leds In Operation

    Check whether the KNX and voltage connec- tions are mixed up. Check the bus connection.   Check whether the power supply is correctly connected. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 52 / 120...

  • Page 53: Configuration

    See Sonos documents with the help of the software supplied with the Sonos com- ponents. Install the ISE SMART CONNECT KNX SONOS on the same See Sonos documents IP network as the Sonos components and make settings on See the router documentation the IP network router if necessary.

  • Page 54: Creating The Device In The Ets

    Commissioning and configuration ISE SMART CONNECT KNX SONOS is now ready for com- missioning via <<Program ETS>> and for testing the func- tions. Configure the playlist for each of the configured master- ► Configure playlists on the device slave groups in the ETS on the device website.

  • Page 55: Setting The Ip Address, Ip Subnet Mask And Standard Gateway Address

    Besides the physical address in the KNX network, an address, the subnet mask and the address of the stand- ard gateway in the IP data network must be assigned to ISE SMART CONNECT KNX SONOS. You can enter the settings manually in the ETS or receive them automatically (obtain the data from a DHCP server, e.g.
  • Page 56 Receive IP address automatically The address data is automatically received from a DHCP server lo- cated on the data network. The DHCP server must assign a valid IP address to ISE SMART CONNECT KNX SONOS. Use fixed IP addresses with DHCP...

  • Page 57: Programming A Physical Address

    Manual: Press the programming button on the device in a particular sequence.  Automated: You select the <<Factory reset>> function on the device website. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 57 / 120...

  • Page 58: Transferring Application Programs And Configuration Data

    Select <<Commissioning>>  <<Programme>>  <<Application program>>. Wait after the download while the device copies the data and installs the application. Commissioning is complete. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 58 / 120...

  • Page 59: Extending The Scope Of Functions (Updating Firmware)

    8.3 Extending the scope of functions (updating firmware) Functional enhancements for ISE SMART CONNECT KNX SONOS are available via a newer version of the firm- ware. Simply download the latest firmware and the relevant product manual from our web site www.ise.de.

  • Page 60: Determining Compatibility Between The Product Database Entry And Firmware Version

    Example 2: Incompatibility if the main version number of the firmware is higher  Firmware version: 2.3  Application program version: 1.3 ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 60 / 120...
  • Page 61 Select the <<Update>> button under the <<Update application program version>> text. Select the newly added device and delete it again from the topology. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 61 / 120...

  • Page 62: Configure Playlists On The Device Website

    The device loads the sources from the <<Sonos playlists>> and <<My Radio Stations>> configured with the Sonos software and any existing external source types. All playlists are displayed first, followed by all stations, all in alphabetical order. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 62 / 120...
  • Page 63 You can also configure the playlists for groups without a connection to the Sonos system to be used at a later point in time. It is thus possible for the end user to configure them before using the ISE SMART CONNECT KNX SONOS.
  • Page 64  If the <<Announcement>> setting is activated, the following set- tings are ignored and hidden on the interface: <<Random func- tion>>, <<Repeat>>. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 64 / 120...
  • Page 65 If the start track happens to be the last track in the playlist, then only this one track is played. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 65 / 120...
  • Page 66 S. 68 Risk of confusion Use the <<Playlist configuration for group>> fold-down list to edit a different master-slave group. Do not select <<Load>>. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 66 / 120...

  • Page 67: Announcement Mode

    Interruption due to selecting another source or due to stopping If the announcement is interrupted by selecting a different source or by stopping, the ISE SMART CONNECT KNX SONOS does not restore the mode active before the announcement.

  • Page 68: Configure New Playlists Faster

    32 GB. The FAT32 file system is supported, and author- isation is read-only. As soon as a microSD card is inserted into the ISE SMART CONNECT KNX SONOS, the contents can be read via the Windows network authorisation.
  • Page 69 You will find the MP3 playlists which you have saved on the microSD card under <<Music Library>>  <<Im- ported playlists>> within the Sonos software. You first need to add a Sonos playlist to use MP3 playlists with the ISE SMART CONNECT KNX SONOS. Use the Sonos software to add lists.

  • Page 70: Configuring Parameters

    Do not use this mode if multiple Sonos devices are available on the local net- work. The selection can change at any time if another Sonos device is detected. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 70 / 120...
  • Page 71 Unlike ticker text, the increment is a full 14 characters, not just one character per telegram. The speed of the block-by-block display can be set with Text display speed. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 71 / 120...

  • Page 72: Group >> Tab (Define Master-Slave Groups)

    <<Group <n>>>  <<Settings>> tab in the configuration for the master-slave group concerned. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 72 / 120...
  • Page 73 Determines the number of slave addresses which can 5 slaves be set. A set of group objects is activated for each slave. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 73 / 120...

  • Page 74: Determine Ip Addresses Of The Sonos Devices In The Data Network

    IP addresses for stereo pairs The Sonos software and the ISE SMART CONNECT KNX SONOS regard a stereo pair as a single (1) "visible" Sonos device. You only need to enter the stereo pair's IP address within the ETS.
  • Page 75 You have entered the IP addresses for the Sonos devices in the configuration for the master- slave groups. The IP address is used to identify the Sonos devices. If a Sonos device now re- ceives a different IP address, it can no longer be addressed via the ISE SMART CONNECT KNX SONOS.

  • Page 76: Communication Objects

    Communication objects 11 Communication objects You can control up to ten master-slave groups with the ISE SMART CONNECT KNX SONOS. There is an identi- cal set of communication objects for each master-slave group. The functionally identical communication ob- jects in the master-slave groups each have an offset of 100.
  • Page 77 Group 1/2/.../10 – Indicates whether music is being played or the music playback is paused or stopped Description: 0 = no playback active 1 = playback running ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 77 / 120...
  • Page 78 Group 1/2/…/10 – Set volume of master (absolute) Description: Enables setting of the volume over the bus: 0 corresponds to 0% 255 to 100% volume ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 78 / 120...
  • Page 79 Enables relative volume adjustment louder/quieter in increments up to 5% using 1-bit group tel- egrams: 0 = quieter by 5% 1 = louder by 5% ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 79 / 120...
  • Page 80 Song Step Function: Group 1/2/.../10 – Skip to next or previous track Description: Switches to the next (1) or previous (0) track. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 80 / 120...
  • Page 81 1..255 starts the playback of the selected playlist which has been configured on the device web- site. ► Configure playlists, p. 62 0 stops the music playback, cancels the source selection and empties the playback queue. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 81 / 120...
  • Page 82 0 = Order of the playlist 1 = Random order You can also configure random playback (<<Random function>> setting) in the playlist configuration on the device website. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 82 / 120...
  • Page 83 Group 1/2/.../10 – Indicates whether playback occurs in a random order Description: 1 = Random order, 0 = Order of the playlist ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 83 / 120...
  • Page 84 Supplies the artist name for the current song as a 14-byte text. The ticker behaviour can be in- fluenced by the parameter settings of the ETS. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 84 / 120...
  • Page 85 Group 1/2/.../10 – Indicates a functioning connection to the playback device. Description: Supplies information on whether the playback device was found on the network. 0 = Not found 1 = Found ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 85 / 120...
  • Page 86 Cause: There is no configuration available for the playlist entry for the master-slave group playlist. Empty playlist slot Solution: Check the playlist configuration on the device website. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 86 / 120...
  • Page 87 You will find the description of error texts in the "Description" column in ► Table 16: Meaning of the error codes (values of communication object <<System status>> 28) and troubleshooting, p. 86. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 87 / 120...
  • Page 88 Group 1/2.../10 – Set group volume (absolute) Description: Enables setting of the group volume over the bus: 0 corresponds to 0% 255 to 100% volume ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 88 / 120...
  • Page 89 Enables relative adjustment (louder/quieter) to the group volume in increments up to 5% using 1-bit group telegrams: 0 = quieter by 5% 1 = louder by 5% ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 89 / 120...
  • Page 90 Supplies the group muting status: 0: At least one loudspeaker in the group is switched on. 1: All loudspeakers are switched off. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 90 / 120...

  • Page 91: Knx Group Objects For Dynamic Group Creation

    Automatic detection (master IP address 0.0.0.0) must not be parametrised, so that group support can be used. You can use the ISE SMART CONNECT KNX SONOS to assign up to five slaves to a master-slave group. The slaves within the master-slave group have an offset of 10 each.
  • Page 92  0: Deactivate active slave.  1: Activate slave. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 92 / 120...
  • Page 93 Group 1/2/.../10 – Indicates whether slave 1/2/3/4/5 has been added to this mas- ter-slave group Description: Supplies information on whether the slave is linked to the master in a group (1) or not (0). ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 93 / 120...
  • Page 94 Group 1/2/.../10 – Set volume of slave 1/2/3/4/5 (absolute) Description: Enables the slave volume to be set over the bus: 0 corresponds to 0% 255 to 100% volume ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 94 / 120...
  • Page 95 Group 1/2/.../10 – Current volume of slave 1/2/3/4/5 Description: Supplies the volume value for the slave over the bus: 0 corresponds to 0% 255 to 100% volume ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 95 / 120...
  • Page 96 Enables relative volume adjustment (louder/quieter) for the group over the bus. Suitable transmitters include push button sensors with the "Brighten/Dim" function, for example. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 96 / 120...
  • Page 97 Enables relative volume adjustment (louder/quieter) for the group in increments up to 5% using 1-bit group telegrams: 0 = quieter by 5% 1 = louder by 5% ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 97 / 120...
  • Page 98 Group 1/2/.../10 – Mutes music playback of slave 1/2/3/4/5 Description: Slave muting: Switches the loudspeaker of the slave off (1) or on again (0). ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 98 / 120...
  • Page 99 Group 1/2/.../10 – Indicates whether slave 1/2/3/4/5 is muted Description: Supplies the slave muting status: 0: Loudspeaker is switched on. 1: Loudspeaker is switched off. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 99 / 120...
  • Page 100 1/2/3/4/5 Description: Supplies information on whether the playback device was found on the network. 1 = Found, 0 = Not found ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 100 / 120...

  • Page 101: Cleaning And Maintenance

    Cleaning and maintenance 12 Cleaning and maintenance ISE SMART CONNECT KNX SONOS is maintenance-free. If necessary, clean the device with a dry cloth. IMPORTANT Damage to the device due to incorrect opening Never open the housing.   If you suspect that the device is damaged, contact our Support.

  • Page 102: Troubleshooting

    Troubleshooting ETS reports the error that it is not pos- Please ensure that your ETS version is up to date. The ISE SMART sible to write on a protected area when CONNECT KNX SONOS requires the ETS in its current version 4 or downloading the application program.
  • Page 103 Troubleshooting Issue Troubleshooting Playlist configuration The <<Playlist assignment>> page is Cause: The ISE SMART CONNECT KNX SONOS device has just empty. been restarted. <<The SonosApp is not active. Please This is normal during the initialisation phase – After about two use the ETS to configure the device.>>...
  • Page 104 The IP address is used to identify the Sonos devices. If a Sonos device now receives a dif- ferent IP address, it can no longer be addressed via the ISE SMART CONNECT KNX SONOS. Solution: Pair the assigned IP address with the MAC address of the Sonos device concerned.
  • Page 105 Radio/line-in can no longer be started This is not an error. with <<Play>> after a <<Stop>>. The ISE SMART CONNECT KNX SONOS's group object <<Stop>> cancels the previously selected source. Solution: Use the group object <<Pause>> to keep the source selec- tion.

  • Page 106: Checking The Device Status

    Error code <<empty slot>> of commu- nication object 29 << System status>> No playlist is found or playlist cannot Cause: In rare cases, the ISE SMART CONNECT KNX SONOS may be played. not be able to retrieve the playlists on your Sonos devices. This means that the playlist website does not offer playlists for selec- tion.

  • Page 107: Generating Log Files

    If necessary, logging mode is configured if Support requires it. Select <<System>>  <<Download log file>> in the menu bar. The log files are compiled and downloaded as a ZIP file. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 107 / 120...

  • Page 108: Contacting Support

    Troubleshooting 13.3 Contacting Support If you have a problem with your ISE SMART CONNECT KNX SONOS and require support, contact us:  E-mail to support@ise.de  Call us on tel.: +49 441 680 06 12  Fax us: +49 441 680 06 15...

  • Page 109: Remote Access

    Why do my KNX operating devices not generate the normal response in my Sonos devices? If the Sonos devices can be operated without any problems using the official Sonos application, please check your ISE SMART CONNECT KNX SONOS's LED display on the device to rule out a fault. ► LEDs in operation, p. 52 13.4.5 Updates...

  • Page 110: Disassembly And Disposal

    Insert a screwdriver (1) into the release lever (2) and push the release lever down (3). Take the device off the top-hat rail. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 110 / 120...
  • Page 111 You can dispose of your old device free of charge at designated collection facilities or, if necessary, you can hand it in to your specialist dealer. Contact your local authority for recycling details. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 111 / 120...

  • Page 112: Glossary

    "catalogue entry". Master Masters are "sound-setting" Sonos devices. Masters control themselves and their slaves. Only masters are able to "command" all functions. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 112 / 120...
  • Page 113 ETS. The product database entry is provided by the devices' manufacturer in the form of a file. The latest version of product data entries of ise Indi- viduelle Software und Elektronik GmbH can be downloaded free of charge from our website www.ise.de.
  • Page 114 These devices are permanently linked to one another. The Sonos software and the ISE SMART CONNECT KNX SONOS regard a stereo pair as a single (1) "visible" Sonos device. Within the ETS, only enter the IP address for the Sonos device which you have assigned as the first device to the stereo pair in the Sonos software.

  • Page 115: Ise Smart Connect Knx Sonos Software Licence Agreement

    16.2 Object of the agreement The object of this agreement is the ISE SMART CONNECT KNX SONOS software provided on data media or through downloads, and the corresponding documentation in written and electronic format.

  • Page 116: Firmware And Hardware

    16.4.4 Transfer to a third party The ISE SMART CONNECT KNX SONOS software must not be passed on to third parties, nor may it be made accessible to third parties. 16.4.5 Renting out, leasing out and sub-licensing The licensee is not authorised to rent or lease the ISE SMART CONNECT KNX SONOS software or grant sub- licenses to the program.

  • Page 117: Changes, Additional Deliveries

    The Licensor shall not be liable for damages due to loss of profit, data loss or any other financial loss result- ing as part of the use of the ISE SMART CONNECT KNX SONOS software, even if the Licensor is aware of the possibility of damage of that type.

  • Page 118: Termination

    The license to use the ISE SMART CONNECT KNX SONOS software shall expire upon termination of the agree- ment. The ISE SMART CONNECT KNX SONOS product must be taken out of operation in such a case. Further use of the ISE SMART CONNECT KNX SONOS without a license is precluded.

  • Page 119: Open Source Software

    The source code for the Open Source software used in this product can be obtained by e-mailing sup- port@ise.de. This offer is valid for 3 years after the discontinuation of the service for this product. ISE SMART CONNECT KNX SONOS 1-0001-002 © 2018 ise Individuelle Software und Elektronik GmbH p. 119 / 120...
  • Page 120 Individuelle Software und Elektronik GmbH Osterstr. 15 26122 Oldenburg, Deutschland Phone +49 441 680 06 11 +49 441 680 06 15 E-mail vertrieb@ise.de www.ise.de...
