1-2 Option Descriptions

1-2 Option Descriptions
This section provides a brief overview of the available options covered in this guide.
Not all instrument models offer every option. For example, Coverage Mapping option is offered
as a 90-day time limited option by ordering Option 9431. The option start time begins when the
Note
user first activates the option. Please refer to the Technical Data Sheet of your instrument for
information on purchasing and activating time limited options

Interference Analyzer (Option 24)

The interference analyzer option includes several features for finding and analyzing interfering signals. This
option adds advanced measurement setups to the basic spectrum analyzer. It additionally adds an Interference
Analyzer mode for displaying signal data on maps to aid in geo-locating interfering signals. Refer to the
sections below for information on each measurement:
• "Interference Finder (Option 24)"
• "AM/FM Audio (Requires Option 24)"
• "Interference Map"
• "Interference Polar"

Zero Span IF Output (Option 89)

Zero span IF output adds an IF output connector to the top panel and additional menu controls to the
FREQ/SPAN menu. Refer to

Gated Sweep (Option 90)

Gated sweep is used for advanced sweep setups and adds additional menu controls to the SWEEP menu. Refer
to "Gated Sweep (Option 90)"

Coverage Mapping (Option 431)

Refer to "Coverage Mapping (Option

EMF Measurement (Option 444)

Refer to "Electromagnetic Field (EMF) Measurements (Option 444)"

Other Options and Features

For descriptions of other options and features not covered in this guide, refer to your instrument user guide or
the product page for a comprehensive list of available documentation.
1-2
"Zero Span IF Output (Option 89)"
431)"section for more information.
PN: 10580-00447 Rev. A
for information about using this feature.
section for more information.
