Install and Submerge the Cleaner

1. With the control box plugged into a GFCI
outlet, spread the floating cable across the
pool deck until you reach the middle of the
pool length.
2. At the center point, submerge the cleaner in
the pool and hold in the vertical position to
release any air trapped inside (Figure 5).
1
Figure 5. Submerge the Cleaner Vertically
NOTE: For optimal patterning and reduced tangling, the floating cable should enter the water near the middle of the pool length.
Only place enough cable in the water to reach the farthest point in the pool (see Figure 14).
cleaner
cleaner
Max
Floating Cable
Length
Figure 7. Pool Entry Point for Optimal Patterning
3. Ensure the unit sinks to the bottom of the
pool and does not float (Figure 6).
2
Figure 6. Cleaner Sinking to the Bottom of the
Pool
4. Place only enough floating cable in the
water to reach the farthest end of your
pool from the central point. Spread out the
floating cable ensuring there are no kinks or
coils in the cable (Figure 7).
Not
Recommended
11.5ft (3.5m) Min
Distance between
the ebox and pool edge
Recommended
entry point
WARNING: Do not use
an extension cord
caddy /
control unit
