Page 18
4
Figure 23. Pull Tabs Through Each Slot
5. Use a pair of scissors to cut the tabs 3/4
inch from the heel so that they are no
higher than the cleaning blade (Figure 24).
6. Repeat the procedure to install the second
brush.
Figure 24. Cut Tabs

Replacing Tracks

1. Pull on the inside of the old track to remove
the track lip from the front wheel
(Figure 25).
Figure 25. Pull the Old Track Over the Wheel
2. Remove the old track from the front wheel,
then remove track from the rear wheel
(Figure 26).
Figure 26. Remove the Old Track
3. Replace the track on the wheel by
positioning the rib toward the body of the
cleaner (Figure 27).
Figure 27. Track Replacement Orientation
4. Push one side of the track on to the wheel
