Keyspan 4-Port Print Server 1.3.1 User Manual page 68

Keyspan:4-Port Print Server - User Manual
allow your computer to communicate with the 4-Port Print Server.
Now that you have your IP address, you will access and configure your Windows XP firewall.
Access Your Firewall
First locate your network connection's icon. To do this, go to the START menu, then to
SETTINGS, then to Network. You should see an icon for your network connection (it is usually
called Local Area Connection). When you see your network connection icon, right-click it to bring
up the sub-menu (see next image):
In the sub-menu, select Properties. This will open the [Local Area Connection] Properties
window. Click on the Advanced tab and then click the Settings button (see next image):
This will open the Advanced Settings window.
In the Advanced Settings window, click the Add button (see next image):
This User Manual applies to the Keyspan 4-Port Print Server Software Version 1.3.x. Patent Pending.
Rev 2005jun23 Page 68
