Project Timber My Den Metal Roof Building Instructions page 5

ID: PT25393
Base Module
1
Base Module fixing
J
I
Side
Front
ID: PT25394
(For each end of the assebled base)
2
Side
I
ID: PT25393
Module I x2
Module J x1
Base Module Woodkits
ID: PT25397
Gable Bearers
Base Module fixing
1220mm
Module
100mm
Screws
Pilot drill
holes before
fixing
Parts List required:
1. Base Module I - 1220mm x 1893mm (2)
2. Base Module J - 585mm x 1893mm (1)
3. Gable Bearers - 38mm x 1817mm (2)
Fixing Kit
3
Base Module fixing
Side
ID: PT25394
585mm
Module
100mm
Screws
Pilot drill
holes before
fixing
