Advantech PCM-24R1TP-BE Startup Manual

PCM-24R1TP-BE
Intel I225, 2.5Gb/s, IEEE 1588, TSN, RJ45*1
Startup Manual

Packing List

Before installation, please make sure that you have:
• mPCIe Card with Controller x 1
• 1 x RJ45 I/O Plate with iDoor bracket x 1
• 1 x wired cable
• 1 x Startup Manual
• 1 x Warranty Card
If anything is missing or damaged, contact your distributor
or sales representative immediately.

Documentation/Software Support

The support documentation and drivers can be accessed
from Advantech website.
• Documentation
• Datasheet
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/
This manual is for the PCM-24R1TP-BE.
Part No. 204324R100
Printed in China

PIN Assignment

Internal Connection
PIN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
1st Edition
May 2020
IO Board & miniPCIE CN1
The Coaxial Cabling form IO board to mPCIe
Coaxial Connector(CN1)
TYPE TYPE
GND GND
PCIE_TXP SMBUS_DAT
PCIE_TXN SMBUS_CLK
GND GND
PCIE_RXP PERST#_CN
PCIE_RXN PCIE_CLKREQ#
GND GND
PCIE_CLK+ +V3.3
PCIE_CLK- +V3.3
GND PCIE_WAKE#
CON_USB2_DP +V3.3
CON_USB2_DN +V3.3
GND W_DISABLE#
CON_USB3_RXDP +V3.3
CON_USB3_RXDN +V3.3
GND NA
CON_USB3_TXDP +V3.3
CON_USB3_TXDN +V3.3
GND NA
NA GND
NA GND
PCM-24R1TP-BE Startup Manual 1
PIN
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
