X
Description:
Syntax:
Values:
Default:
Result Codes:
Call Progress Result Codes:
Z
Description:
Syntax:
Values:
Default:
Result Codes:
Multi-Tech Systems, Inc. AT Commands for the MultiModem & SocketModem MT9234 Series (S000434H)
Downloaded from Elcodis.com electronic components distributor

Select Result Code and Monitor Call Progress

Use this command to enable tone detection options used in the dialing process. As
each function is chosen, the modem's result codes are also affected. Therefore, this
command is frequently used to control the modem's responses. The primary function
of this command is to control call response capabilities.
Function
Ext Result Codes
Dial Tone Detect
Busy Tone Detect
ATX<value>
Command Extended Result Codes Dial Tone Detect
0 Disabled
1 Enabled
2 Enabled
3 Enabled
4 Enabled
5, 6 Enabled
7 Disabled
4
OK if <value> = 0 to 7.
ERROR if <value> ≠ 0 to 7.
Command Result Codes
0 OK, RING, ERROR, CONNECT, NO CARRIER
1 OK, RING, ERROR, CONNECT<RATE>, NO CARRIER
2 OK, RING, ERROR, CONNECT<RATE>, NO CARRIER, NO DIALTONE
3 OK, RING, ERROR, CONNECT<RATE>, NO CARRIER, BUSY,
BLACKLISTED
4 OK, RING, ERROR, CONNECT<RATE>, NO CARRIER, BUSY,
BLACKLISTED, DELAYED, NO DIALTONE, CALL WAITING
DETECTED
5, 6 OK, RING, ERROR, CONNECT<RATE>, NO CARRIER, BUSY,
BLACKLISTED, DELAYED, NO DIALTONE, CALL WAITING
DETECTED
7 OK, RING, ERROR, CONNECT, NO CARRIER

Reset and Recall Stored Profile

Use this command to make the modem go on-hook and restore the profile saved by
the last &W command.
Note: Both Z0 or Z1 restore the same profile (See &W – Store Current Configuration).
Agere Systems controller-based modems have only one stored profile.
ATZ<value>
0 Reset and restore stored profile (saved by the last &W command).
1 Same as Z0.
None
OK if <value> = 0 to 1.
ERROR if <value> ≠ 0 to 1.
Chapter 1 – AT Commands, S-Registers, and Result Codes
Enabled
Modem displays basic result
codes, connect messages with
data rate, and an indication of
the modems error correction
and data compression
operations.
Modem dials upon detection of
a dial tone, and disconnects the
call if the dial tone is not
detected within 10 seconds.
Modem monitors for busy tones.
Disabled
Disabled
Enabled
Disabled
Enabled
Enabled
Enabled
Disabled
Modem displays the basic
result codes.
Modem dials a call regardless
of whether it detects a dial
tone. Register S6 contains
the dial delay.
Modem ignores any busy
tones it receives.
Busy Tone Detect
Disabled
Disabled
Disabled
Enabled
Enabled
Enabled
Enabled
13
