mAKErBOT rEPLiCATOr 2 DiAgrAm
[1] gANTry SySTEm
[2] LCD PANEL
[3] KEy PAD
[4] ThrEADED z-AxiS rOD
[5] BUiLD PLATE
[6] BUiLD PLATFOrm
[7] FiLAmENT gUiDE TUBE
[8] ExTrUDEr CABLE
[9] ExTrUDEr
[10] FiLAmENT SPOOL
[11] SPOOL hOLDEr
B SETTING UP YOUR MAkERBOT REPLICATOR 2 DESkTOP 3D PRINTER
1
4
5
6
9
2
7
3
8
10
11
13
