Battery Level Indication - Fenix E-CP User Manual

2. Properly connect the light and the device to be charged via the charging cable to begin
discharging, the indicators will recede from right to left to display the status. Only Eco, Low and
Med modes are available when discharging.
3. Be sure to close the anti‐dust cover once discharging is completed.
Note:
1. The USB‐A port of the light ONLY supports discharging and the USB Type‐C port of the light
supports charging and discharging. Both ports support 5V/2.4A, 9V/2A, 12V/1.5A. The fast
charging function only normally works when charging cable, adapter and the digital device to be
charged support fast charging. The included charging cable supports fast charging function.
2. Timely charge the light to ensure the normal life of the battery when the battery power is too
low.
3. Recharge a stored light every four months to maintain the optimum performance of the
battery.
Battery Level Indication
With the light switched off, single click the side switch to check the battery status, which will last
for 5 seconds.
Four lights on: 80% ‐ 100%
Three lights on: 60% ‐ 80%
Two lights on: 40% ‐ 60%
One light on: 20% ‐ 40%
One light flashes: less than 20%
Note: When charging the light or using the power bank function, the indicators will constantly
indicate the battery status, and when using the light, the indicators will intermittently indicate
the battery status.
