Operating Instruction - Fenix E-CP User Manual


Boot‐up battery level indication and low‐voltage warning.

Made of durable A6061‐T6 aluminum.

Premium type HAIII hard‐anodized anti‐abrasive finish.

5.43'' x 1.10'' / 138 x 28 mm.

6.00 oz / 170 g (including battery).
Operating Instruction
On/off
With the light unlocked, press and hold the side switch for 0.5 seconds to turn on/off the light.
Instant Strobe
With the light unlocked, press and hold the side switch for 1.2 seconds to enter Strobe mode,
single click again to return to the previously used output of General mode.
Output Selection
In General mode, single click the side switch to cycle through Eco→Low→Med→High→Turbo.
Lock/Unlock
Lock: with the light unlocked and switched off, double click the switch within 0.5 seconds to lock
the light, the light will blink twice on Low to indicate locked status.
Unlock: with the light locked, double click the switch within 0.5 seconds, the light will be
unlocked and activated on Eco. When charging the flashlight, it also will be unlocked.
*In locked status, clicking or pressing the switch will activate 2 one‐second blinks on Low to
indicate locked status.
