Fenix E02R Manual

Download this manual

Technical Parameters

ANSI/ PLATO FL1

Output

Runtime

Distance

Intensity

Impact Resistance

Submersible

Note: According to the ANSI/PLATO FL1 standard, the above specifications are from the results

produced by Fenix through its laboratory testing using the built-in 120 mAh Li-polymer battery

under the temperature of 21±3°C and humidity of 50% - 80%. The true performance of this

product may vary according to different working environments and the actual battery used.

*The High output is measured in total of runtime including output at reduced levels due to

temperature or protection mechanism in the design.

Product Features

200 lumens maximum output; 49 meters maximum beam distance.

Fenix E02R Flashlight

High

200 lumens *

25 minutes

49 meters

591 candela

1 meter

IP68

Low

15 lumens

6.5 hours

13 meters

39 candela

Need help?

Do you have a question about the E02R and is the answer not in the manual?

Page 1 Note: According to the ANSI/PLATO FL1 standard, the above specifications are from the results produced by Fenix through its laboratory testing using the built-in 120 mAh Li-polymer battery under the temperature of 21±3°C and humidity of 50% - 80%. The true performance of this product may vary according to different working environments and the actual battery used.
Page 2 Cree XP-G2 S3 white LED, with a lifespan of 50,000 hours. Built-in 120 mAh Li-polymer battery. Micro USB charging port for direct charging. Twisty head for on/off and brightness selection. Integrated design of light head and tail. High-efficiency lens with total reflective coating. Made of durable A6061-T6 aluminum.
Page 3 Long-term use can result in O-ring wear. To maintain a proper water seal, replace the ring with an approved spare． Included Fenix E02R flashlight, Micro USB charging cable, Key chain, Spare O-ring, User manual, Warranty card Warning This flashlight is a high-intensity lighting device capable of causing eye damage to the user or others.
