Remove the TORX25 screw
from the centre of the cover
and slide the cover back in
order to remove the plug.
NOTE: The actuator plug
only goes in one way. The
incut portion of the plug is on
the side indicated by the
red
arrow
in the adjacent photo.
Now that both the power
cable and the actuator cable
are separated from the unit
the sensor may be removed
by unscrewing the four M6
screws.
21
