Should further adjustment be necessary, follow the steps in the next 2
illustrations. Should the angle be satisfactory as it is, then tighten the bolts as
shown.
Once the sled is correctly adjusted, the equipment is ready for use.
5 adjustment positions each
side for angle of sled to
ground (shroud not shown)
Only 1 pair of holes will line
up at any time
9
