To fit the draw-bar:

1. Place in position behind the vehicle.
2. Slide the drawbar into approximate position ensuring tow hitch is the
correct way up.
3. Attach screw-lock power cable together.
4. Fit front adjustment bolts to suit ATV or other towing vehicle.

Adjusting the angle of sled

Remove the front drawbar bolts and select the appropriate angle depending on
towing vehicle and terrain. Experience will determine the best angle for the
terrain being traversed.
The operator should exercise care and common
sense when determining the speed to be traveled.
The equipment is designed to travel at up to
20kph on ideal terrain. This maximum speed
applies regardless
measuring or in transit. If the surface is rough, or
if obstacles are present, then a much slower
speed should be used.
of whether the unit is
