Check Clearance On Sled Movement - C-Dax pasture meter+ Operation Manual

Check Clearance on sled movement

Attach coupling on the sled to the tow-ball on the ATV. Ensure wheels are down
in the transport position.
Connect the 12v power cable to the sled.
Maneuver sled to extreme left and right positions to ensure cable will not foul
wheels and not be damaged by hot exhaust pipe or hot exhaust emissions.
CAUTION
Exercise caution around the moving parts of the Pasturemeter+. The sled
will automatically return to its wheels down state whenever power is
initially connected. Keep hands away from all moving parts of the sled and
feet clear of the underside of the sled.
WARNING
Ensure that the power cable is disconnected when uncoupling the sled
draw-bar. Moving the towing vehicle away from the sled with the cables
attached could result in damage to the cable and/or connectors.
10
