- Page 1 OWNER’S MANUAL FOR THE MAGNESIUM OXIDE SPREADERS MAGMASTER C-Dax Ltd PO Box 1010, 145 Harts Road Tiritea, Palmerston North Ph:06 354 6060 Fax:06 355 3199 E-Mail: sales@c-dax.co.nz www.c-dax.co.nz...
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS MAGMASTER 65/165 AN IMPORTANT MESSAGE FOR OWNERS & OPERATORS OF C-Dax ATTACHMENTS/ACCESSORIES Be warned of the dangers of loading your ATV or other vehicle in excess of its carrying capacity. It is important to understand that any loads or attachments whether fastened to or placed on a vehicle or ATV will alter the stability or handling characteristics of that vehicle or ATV. - Page 3 SAFETY PRECAUTIONS Before attempting to install or operate the equipment, read and understand the manual thoroughly. Failure to comply with this instruction constitutes improper use and will invalidate the warranty. Throughout this manual there are highlighted text boxes containing warnings, cautions and notes. Warnings are mandatory instructions to prevent serious injury or permanent damage.
-
Page 4: Table Of Contents
C-Dax MAGMASTER OWNER’S MANUAL (Pt.No.2400-6600 Issue 14, August 2022) TABLE OF CONTENTS Safety Precautions Table of Contents Introduction Description Specifications Order Information Warranty Liability Operation Assembly Calibration Operating the Spreader Maintenance Before Use After Each Use and Daily When in Use... -
Page 5: Introduction
INTRODUCTION Congratulations. You have just purchased an advanced spreader from C-Dax Ltd. C-Dax Ltd is committed to providing you, the farmer, with quality applicating systems. DESCRIPTION The C-Dax MagMaster is a ground-driven spreader designed specifically for the application of powdered Magnesium Oxide, available in 2 size options, 65L or 165L. -
Page 6: Liability
U.K.) subject to the terms set out below. C-Dax will at its option repair or replace the defective equipment (or part of the equipment) or notify the retailer of the equipment to refund the purchase price for such defective equipment to you in the event of a breach of this warranty, subject to the terms set out below. - Page 7 Where C-Dax elects to repair or replace the equipment it will use reasonable endeavours to do so as soon as practicable but will not be liable for any delay in doing so.
-
Page 8: Operation
OPERATION The product to be spread is placed in the hopper. When the spreader is towed forward, the right hand wheel drives through the pin clutch and gearbox to turn the spinner in a clockwise direction. When the control handle is pulled forward, the shutter at the bottom of the hopper rotates to an open position. The size of the opening is set by the adjustable stop pin, which locates into one of five pre-set positions. -
Page 9: Calibration
CALIBRATION Magnesium Oxide powder is applied at a rate determined by the number of cows to be treated. When spreading this product, calculate the weight of powder to be applied and apply this amount with the adjustment stop pin in position 1-5. Use the table below to work out which setting is most appropriate. Magmaster 65L Nominal application rates (grams/m ) for Magnesium Oxide spread at 10Kph Adjustment Stop Pin... -
Page 10: Operating The Spreader
OPERATING THE SPREADER When the spreader has been correctly calibrated, the hopper may be filled to the required level and spreading commenced. To reduce agitator damage to product and to ensure that product is not forced past the agitator shaft when towing the spreader to the area to be treated, the drive to the gearbox should be disconnected by removing the pin from the drive axle. -
Page 11: Maintenance
MAINTENANCE WARNING Magnesium Oxide will set hard if exposed to air, it is of utmost importance that the spreader be cleaned of all product even if stored for a short time. Load the spreader only with the amount required to be spread and clean all traces of product from the machine after use. - Page 12 EXPLODED DIAGRAM Magmaster 65...
- Page 13 PARTS LIST Magmaster 65 Item QTY. e9 part no e9 description 1036-8230 Agitator-Spreader-Magmaster-SS 1140-1200 Bearing-Ball-Pillow Block-Drive Axle-Spreaders 1140-4000 Bearing-Housing-Pillow Block-Drive Axle-Spreaders 1300-4100 Bracket-Drive-130L/MAG/165L-Spreaders-ZP 1300-4550 Bracket-Handle Position-Index-RH-MM65-ZP 1300-6800 Bracket-Mudguard-CDIT300/400/MM165-LH-GL 1300-6801 Bracket-Mudguard-CDIT300/400/MM165-RH-GL 2050-7300 Clip-R Type-Pin-2.5MM-ZP 2230-1100 Cord-Arrestor-Hinged Spreader Lid 2250-1000 Cover-Axle Shaft-55mm Long-Spreader 130L/165L/Magmaster-SS...
- Page 14 6500-7800 Profiled-Shutter-Magmaster-Spreader-Stainless 6500-9000 Profiled-Washer-Spinner Shaft-34.9x67x2mm-Stainless 304 7500-2000 Rota-Hinge-LH-SM70/75 7500-2010 Rota-Hinge-RH-SM70/75 7500-2180 Rota-Hopper-Spreader-Magmaster -Yellow-MDPE 7500-2520 Rota-Lid-Hopper-SM70/75L 7500-2590 Rota-Mudguard-Blue-MDPE-1/4 Circle 7500-2700 Rota-Shroud-Spreader Magmaster-Yellow-MDPE 8200-5000 Spinner-Magmaster 65-SS 8200-5100 Spinner-Mount-Magmaster 65-ZP 8250-1800 Spring-Compression-Crinkle Plate-ZP 8800-3800 Tow-Coupling-Handle-Double Ended-1 78 x 50mm-ZP 9200-8610 Wheel-Turf-DRILLED-DRIVE-18x750x8-Tubeless 9200-8600 Wheel-Turf-Bearing-18x750x8-Tubeless...
- Page 15 EXPLODED PARTS DIAGRAM Magmaster 165...
- Page 16 PARTS LIST Magmaster 165 Item QTY. e9 part no e9 description 1036-8223 Agitator-Spreader-165L/Magmaster 165-SS 1110-2308 Ball-End-Internal Thread-M8-Zinc Plated 1140-1200 Bearing-Ball-Pillow Block-Drive Axle-Spreaders 1140-4000 Bearing-Housing-Pillow Block-Drive Axle-Spreaders 1300-4100 Bracket-Drive-130L/MAG/165L-Spreaders-ZP 1300-6800 Bracket-Mudguard-CDIT300/400/MM165-LH-GL 1300-6801 Bracket-Mudguard-CDIT300/400/MM165-RH-GL 1455-8800 Button-Ute Cover-Bungy Cord Retain-Black-Plastic 2250-1000 Cover-Axle Shaft-Spreader 130L/165L/Magmaster-PVC 2250-4150 Cover-Hopper-Silver Fabric-Spreader130/165 2550-8203...
- Page 17 6500-4201 Profiled-Index-Plate-MAG/130L/165L Spreader-ZP 6500-7770 Profiled-Shutter-CDIT300/400 7500-2185 Rota-Hopper-Spreader-Magmaster 165L-Yellow-MDPE 7500-2590 Rota-Mudguard-Blue-MDPE-1/4 Circle 7500-2705 Rota-Shroud-Spreader Magmaster 165L-Yellow-MDPE 7500-2830 Rota-Spout-Spreader-CDIT400GT-Yellow-MDPE 8200-2105 Disc-Spinner-Base-Flat-C-Dax 300/400/1300-Spreader-Stainless 8200-5305 Spinner-Mount-Spreader 165L/Magmaster 165-ZP 8250-1800 Spring-Compression-Crinkle Plate-ZP 8800-3800 Tow-Coupling-Handle-Double Ended-1 7/8" x 50mm-ZP 8910-8005 Vane-Spinner-Magmaster 165L-SS 9200-8610 Wheel-Turf-DRILLED-DRIVE-18x750x8-Tubeless 9200-8600 Wheel-Turf-Bearing-18x750x8-Tubeless...
