OWNER'S MANUAL
FOR THE
TURF & GARDEN
TURFMATE & LINEMARKER
C-Dax Ltd
PO Box 1010, 145 Harts Road
Tiritea, Palmerston North
Ph:06 354 6060
Fax:06 355 3199
E-Mail: sales@c-dax.co.nz
www.c-dax.co.nz

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GM20 and is the answer not in the manual?

Questions and answers

Summary of Contents for C-Dax GM20

  • Page 1 OWNER’S MANUAL FOR THE TURF & GARDEN TURFMATE & LINEMARKER C-Dax Ltd PO Box 1010, 145 Harts Road Tiritea, Palmerston North Ph:06 354 6060 Fax:06 355 3199 E-Mail: sales@c-dax.co.nz www.c-dax.co.nz...
  • Page 2 Equipment Affected: GM20, GM50, TURFMATE, LINEMARKER Background: The rechargeable battery sold with the affected equipment is a lead-acid type. Analysis of battery failures reported to C-Dax over a two-year period shows that nearly all failures resulted from improper maintenance of the battery.
  • Page 3: Table Of Contents

    C-Dax TURF & GARDEN Professional TURFMATE & LINEMARKER OWNER’S MANUAL (Pt.No.2400-6500 Issue 9 Dated February 2011) TABLE OF CONTENTS Contents Introduction Description TurfMate LineMarker Specifications Order Information TurfMate LineMarker Warranty Liability Installation Installing the Battery Precautions Recharging TurfMate Installation Cont.
  • Page 4: Introduction

    Features of the TurfMate include a 50L polyethylene tank, precision 2m boom, unique breakaway system, low voltage 12V pump and accurate pressure gauge. C-Dax acknowledges the co-operation and assistance of New Zealand Turf Culture Institute.
  • Page 5: Warranty

    All goods returned to C-Dax Ltd are freight paid by the sender and if subject to a warranty claim, must be accompanied by a completed warranty claim form. Warranty claim forms are available from C-Dax dealers.
  • Page 6: Installation

    INSTALLATION For transport purposes, both the TurfMate and LineMarker are sent disassembled – hence some assembly by the user is required. The following parts are included: Handle Assembly Owner’s Manual Battery Charger Battery Cable Front Wheel Assembly Lead-Acid Battery Maintenance Leaflet Battery Nuts and Bolts etc.
  • Page 7: Turfmate Installation Cont

    TURFMATE INSTALLATION CONT. Fix the boom frame to the boom mount by sliding through the bracket and fixed using the M8 x 40 screw, nut and washer supplied. Assemble the boom by pressing the button latch on each arm and sliding the arm into the boom frame (See the parts diagram for further detail).
  • Page 8: Theory Of Operation

    THEORY OF OPERATION Spray fluid is prepared and placed in the tank via the lid opening and strainer basket. Foreign matter is trapped in the strainer mesh for disposal after the tank has been filled. When the pump is switched on power is applied to the pump motor from the battery. When the pump operates, fluid is drawn through the filtered suction line into the pump head.
  • Page 9: Operating Instructions (Linemarker)

    OPERATING INSTRUCTIONS (LINEMARKER) Nozzle flow rate is determined by the pump outlet and the size of restrictor at the return elbow. Application rate will depend on nozzle flow rate and forward speed. Therefore to vary the concentration of marker dye on the line the operator can vary speed, or if absolutely necessary by altering the size of restriction.
  • Page 10: Maintenance

    MAINTENANCE Keep the sprayer in good condition. Cleanliness and maintenance are essential for safe and trouble free operation. Cleaning Flush unit out after use with a mild detergent solution. Leave fresh water in the pump system for storage. The boom may need thorough flushing after using wettable powders. Remove the nozzle caps at either end of the boom and pump about 20 litres of clean water through the boom.
  • Page 11: Nozzle Body Parts Diagram

    NOZZLE BODY PARTS DIAGRAM ITEM NO. Part No DESCRIPTION 5300-1800 Nozzle Body (INCL. everything except 10,12 & 13) 6220-2000 Piston Assembly 2300-4390 Diaphragm Only 6200-5490 Fly Nut – ¾” Part of 5300-1800 Swivel Clamp Part of 5300-1800 Swivel Clamp Pin 5500-4040 O-Ring 3280-0634...
  • Page 12: Linemarker Parts Diagram

    LINEMARKER PARTS DIAGRAM...
  • Page 13: Linemarker Parts List

    LINEMARKER PARTS LIST...
  • Page 14: Turfmate Parts Diagram

    TURFMATE PARTS DIAGRAM *FOR BREAKDOWN OF TURFMATE BOOM SEE PAGE 17.
  • Page 15: Turfmate Parts List

    TURFMATE PARTS LIST...
  • Page 17 FLOJET SPRAY PUMP RELACEMENT PARTS The following replacement parts for the 12V Flojet 7.6 L/Min pump are available from any C-Dax dealer: NOTE Please select the correct hose connection type for your pump Quadport Type: Screw Type: ITEM PART NO.
