IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
For assembly see instructions in carton 6800-201.
home
6800-202
Sofa Table
B.
Side
2 pcs.
styles Customer Service: www.homestylesfurniture.com,
servicedesk@homestylesfurniture.com,
888-680-7460
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Homestyles 6800-202
Summary of Contents for Homestyles 6800-202
- Page 1 6800-202 Sofa Table IMPORTANT Carefully remove all the parts from the carton and place them individually on a soft cloth to prevent scratches or other damage. Carefully and strictly follow these assembly instructions to ensure a completed product as designed.
- Page 2 Flat Washer Plug 1 pc. 1 pc. 16 pcs. (+1 extra) 16 pcs. (+1 extra) 16 pcs. (+1 extra) 3 pcs. Carton 6800-202 is also needed for assembly. Tool(s) required for assembly: Level home styles Customer Service: www.homestylesfurniture.com, servicedesk@homestylesfurniture.com, 888-680-7460...
- Page 3 Assembly Instructions 2/6 IMPORTANT Ÿ Use a soft cloth between these parts and the floor. Ÿ Do not use power tools above 8 volts to assemble. Ÿ Do not tighten all the bolts until each part is properly assembled. Ÿ The unit must be level to work properly.
- Page 4 Assembly Instructions / 3 6 Flat Washer Spring Washer Head Cap Bolt STEP 2 Attach Side (B) to unit with Head Cap Bolts, Spring Washers and Flat Washers, tightening bolts only halfway. Tighten all bolts used in Steps 1 and 2.
- Page 5 Assembly Instructions / 4 6 Head Cap Bolt Spring Washer Flat Washer STEP 3 Turn unit upside down. Attach Feet (E) to unit with Head Cap Bolts, Spring Washers and Flat Washers. (See Figure 2) Figure 2...
- Page 6 Assembly Instructions / 5 6 STEP 4 Turn over unit to its upright position. Place Containers (F) into position. Place Plugs into position.
- Page 7 Assembly Instructions / 6 6 STEP 5 Place Tops (D) into position. Level unit by adjusting the adjustable levelers on bottom of unit. (See Figure 3) Figure 3...
- Page 8 Digital images of the defective parts may be required. If the product was not purchased from an authorized retailer, homestyles is under no obligation to provide replacement parts. Parts are not available for fully assembled items nor are parts available for sale. Replacements for missing or damaged parts may be requested via contact info below.
