Thank you for purchasing the FUNN STRYGE STEM.
Please read these instructions thoroughly before attempting to install this item.
Following all fitting instructions in order is required for compliance with FUNN's warranty policy.

tools required

. Hex key 4mm

contents

. Stryge stem

Steerer tube preparation

. Stryge stem requires a 28.6mm (1 1/8") steerer tube.
Ensure the steerer tube is the correct length – there should be 2-3mm gap from the top of the spacer or stem
to the top of the steerer tube. If the steerer tube requires modifying to fit, ensure it is cut level.

stem installation

1.
Remove all bolts. Grease the threads and under the heads.
2.
Ensure the external surface of the steerer tube is both
clean and dry. Slide the stem onto the steerer, depending
on the rise or drop required.
WWW.FUNNMTB.COM
STRYGE STEM 2022.09.01 / REV. 0
. Torque wrench
1 PC
3.
Fit the top cap and tighten the headset pre-load bolt to
remove any play while keeping the steering smoothly.
STRYGE STEM
INSTALLATION AND USE
2 to 3mm gap from
top of stem
to top of steerer tube.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STRYGE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Funn STRYGE

  • Page 1 INSTALLATION AND USE Thank you for purchasing the FUNN STRYGE STEM. Please read these instructions thoroughly before attempting to install this item. Following all fitting instructions in order is required for compliance with FUNN’s warranty policy. tools required . Torque wrench ....
  • Page 2 Please check the torque for all the bolts twice a year. Please also inspect the stem and handlebar for damage and visible cracks. If any damage, please stop using the part. It should be replaced immediately. Failure to do so may result in serious injury. WWW.FUNNMTB.COM STRYGE STEM 2022.09.01 / REV. 0...
