ATTACH PEDALS TO CRANKS

Pedals have 9/16" x 20T threaded axles. The right pedal is installed in a clockwise
direction. The left pedal is installed in a counter-clockwise direction.
1.Lightly lubricate axle threads with grease or oil.
2.Thread axle into the crank hole with your fingers. From the other side of the crank,
insert 6mm Allen key into the recess of the axle. Screw pedal axles onto crank
arms.
3.Tighten to 34 Nm (300 lb-in) torque and avoid excessive force.

GRIP PINS

You can remove the pins on the pedals to fine tune the grip. Damaged or worn grip
pins can be replaced using 4 mm socket wrench.

GRS SYSTEM

BIGFOOT features the GRS system for easily lubricating the bushing .
1.Use 2mm Allen key to remove the GRS screw.
2.Lubricate the bushing with a synergy and wipe of the excessive oil.
3.Tighten the screw back on to seal the GRS port.
6mm Hex Key
INSTALLATION AND USE
